VX2360-03 3/8'' SMC Type Brass Solenoid Valve For Water Air 220V 110V 24V

VX2360-03 3/8'' SMC Type Brass Solenoid Valve For Water Air 220V 110V 24V

  • VX2360-03 3/8'' SMC Type Brass Solenoid Valve For Water Air 220V 110V 24V
  • VX2360-03 3/8'' SMC Type Brass Solenoid Valve For Water Air 220V 110V 24V
VX2360-03 3/8'' SMC Type Brass Solenoid Valve For Water Air 220V 110V 24V
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: VX2360-03
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: Negotiation
Packaging Details: Box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: T/T, PayPal, Western Union
Supply Ability: 50000pcs per month
Chat Now
Detailed Product Description
Product Name: Solenoid Valve Port Size: 3/8''
Orifice Size: 13mm Body Material: Brass
Seal Material: NBR, EPDM, FKM Working Medium: Air, Water, Gas, Liquid, Steam, Etc
Medium Temperature: NBR: -5 To +80℃, EPDM: -5 To +120℃, FKM: -10 To +150℃ Working Pressure: 0 To 1 MPa
Operation: Direct Lifting Diaphragm Function: 2 Way, Normally Closed
Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Highlight:

SMC Solenoid Valve VX2360-03

,

SMC Solenoid Valve 3/8''

,

SMC Solenoid Valve 220V

VX2360-03 3/8'' SMC Type Brass Solenoid Valve For Water Air 220V 110V 24V



Product Features:

1. Working Media: Air, Water, Gas, Liquid, Steam, etc
2. Working Pressure: 0 to 10 bar
3. Medium Temperature: NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -10 to +150℃
4. Port Size: 3/8'', 1/2''
5. Orifice Size: 10mm, 13mm
6. Body Material: Brass
7. Seal Material: NBR, EPDM, FKM
8. Function: 2 Way Normally Closed
9. Operation: Direct Acting
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC



Technical Data:

BRANDO Model
VX2260-03
VX2360-03
VX2360-04
Ref No
VX2120-10
VX2130-10
VX2130-15
Orifice Size
10mm
13mm
13mm
Port Size
3/8''
3/8''
1/2''
Medium
Water, Air, Gas, Liquid, Steam, etc
Operation
Direct Acting
Function
2 Way Normally Closed
Body Material
Brass
Seal Material
NBR, EPDM, FKM
Medium Temperature
NBR: -5 to +80℃
EPDM: -5 to +120℃
FKM: -10 to +150℃
Working Pressure
0 to 10 bar
Voltage
12VDC, 24VDC, 24VAC, 110VAC, 220VAC, other voltages can be customzied



Main Dimension:

VX2360-03 3/8'' SMC Type Brass Solenoid Valve For Water Air 220V 110V 24V 0

BRANDO Model
Port
A
B
C
VX2260-03
(VX2120-10)
3/8''
40
50
80
VX2360-03
(VX2130-10)
3/8''
40
50
80
VX2360-04
(VX2130-15)
1/2''
48
66
110



Our Production:

VX2360-03 3/8'' SMC Type Brass Solenoid Valve For Water Air 220V 110V 24V 1



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
