Focus on your demands
Offer you best solution
Sales & Support:
 |
| Place of Origin: | CHINA |
| Brand Name: | BRANDO |
| Certification: | CE |
| Model Number: | CA76MM |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 days |
| Payment Terms: | T/T, PayPal, Western Union, L/C |
| Supply Ability: | 100000 pieces per month |
| Port Size: | 3'' | Valve Series: | MM |
|---|---|---|---|
| Valve Structure: | Manifold Mount | Diaphragm Material: | NBR, FKM |
| Working Pressure Range: | 0.35 To 0.85 MPa | Coil Voltage: | 24VDC, 110VAC, 220VAC |
| Highlight: | Goyen Pulse Valve CA76MM,Goyen MM Series Pulse Valve,Goyen CA76MM040-305 |
||
CA76MM Goyen Type MM Series Manifold Mount Pulse Jet Valve
The full immersion manifold flat mount valves deliver the most powerful air pulse in square tank systems. These diaphragm valves are designed for dust collectors and baghouses with reverse pulse jet filter cleaning systems. Pulse valves (also called diaphragm valves) are the “switch” for compressed air in the dust clean blowing system of the pulse bag filter. It is used to control the release of air pulses in the cleaning cycle. When the dust collector control board starts the cleaning cycle, it sends an electrical signal to the solenoid valve, and then activates the pulse valve. Inside the pulse valve, the rubber diaphragm opens and closes to release the compressed air stored in the air header. At this time, the air enters the blowing pipe above the filter through the valve, and then enters the filter down to clean the filter bag.
Technical Data of MM Series Pulse Jet Valves:
|
Model No
|
CA25MM
|
CA40MM
|
CA50MM
|
CA62MM
|
CA76MM
|
CA102MM
|
||
|
Nominal Size
|
25
|
40
|
50
|
62
|
76
|
102
|
||
|
Port Size
|
mm
|
25
|
40
|
50
|
62
|
76
|
102
|
|
|
inch
|
1''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
3 1/2''
|
4''
|
|
|
Pressure Range
|
0.35 to 0.85 MPa
|
|||||||
|
Temp.
Range
|
NBR
|
-40 to 82 ℃
|
||||||
|
FKM
|
-29 to 232 ℃
|
|||||||
Ordering Code of MM Series Pulse Jet Valve:
Main Dimension of CA76MM Pulse Jet Valve:
Video of CA76MM Pulse Jet Valve:
More Goyen Type Pulse Valves for you to choose:
|
|
|
|
| T Series | DD Series | FS Series | MM Series |
|
|
|
|
| RCA Series | Solenoid Coil | Solenoid Armature | Diaphragm |
