3 Inch Joil Type Solenoid Valve Diaphragm Pulse Valve Repair Kit Black Nitrile Rubber Diaphragm Model J76

Pulse Valve Repair Kit 3 Inch Joil Type Black Nitrile Rubber Diaphragm Model No.J76

The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life, even under harsh conditions.The design with integral compression fittings will facilitate installation because there is no need forthreaded piping.
The high flow, angle type bodies in combination with the special main diaphragm assemblies give the unique operating features required for pulse jet valves service applications.

If you need a large quantity, we can give a big discount for you. Welcome your inquiry.Note: the Viton ( for high temperature performance ) material is also available.

The other types also can be supplied

Application in Industrial Dust Collector Filtration

Definition:

Pulse valve diaphragm commonly used material is rubber. The rubber diaphragm is mainly used in valves, regulating valves, automatic mechanical follow-up devices, switches and counters of flow rate, pressure, differential, liquid level, constant temperature and volume thermal compensation, etc. Its advantages are high reliability, good complexity, long working life and low cost. Uniform elastic construction can be used in all kinds of rubber. The rubber diaphragm has a long service life and can perform the operation synchronously with other control components to ensure the pulse compressed air injection. Even in extremely harsh working conditions, it can guarantee its normal work and long service life.

The operating temperature and pressure range of the diaphragm itself depends on the rubber, fabric and structure. The diaphragm can work at -50~100 ° c and 0.4~ 0.8mpa. Fluoro rubber and silicone rubber diaphragm can work at -80~232 ℃. Chlorol rubber diaphragm can work under pressure of 0.4~ 0.8mpa, with good air tightness and aging resistance.

Electromagnetic pulse valve diaphragm operation

Pulse valve diaphragm, is the electromagnetic pulse valve air switch, electromagnetic pulse valve diaphragm back control pressure gas quickly discharged. Diaphragm front control pressure gas will lift the diaphragm, open the electromagnetic pulse valve channel into the bit on the injection, the electrical signal disappears, the electromagnetic pilot head of the spring make the moving column immediately reset closed unloading hole. Electromagnetic pulse valve diaphragm control gas pressure and diaphragm spring force after close the channel, the electromagnetic pulse valve to stop the resistance of injection on the diaphragm hole, when the guide head moving column is raised, when gas pressure unloading, electromagnetic pulse valve diaphragm have the effect of air resistance, when unloading closed cavity, after pressure gas is quickly to make the electromagnetic pulse valve diaphragm close the channel, stop blowing.
