Name: Air Working Medium ASCO Submergerd Type Pneumatic Pulse Valve QK25 With Port Size 1 Inch
Brand: Ningbo Brando Hardware Co., Ltd
SKU: QK25
Price: Negotiable USD
Availability: InStock

Home Products Pulse Jet Valve

Air Working Medium ASCO Submergerd Type Pneumatic Pulse Valve QK25 With Port Size 1 Inch

Product Details:

Place of Origin:	China
Brand Name:	OEM
Certification:	ISO、CE
Model Number:	QK25

Payment & Shipping Terms:

Minimum Order Quantity:	1Pcs，Sample Available
Price:	Negotiation
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	Negotiation
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Port Size:	1"	Material:	Aluminum
Media:	Air	Application:	Dedusting
Power:	Pneumatic	Type:	Submerged
Highlight:	ASCO Pulse Valve , ASCO Diaphragm Valve , ASCO Pulse Jet Valve

Air Working Medium ASCO Submerged Type Pneumatic Pulse Valve QK25 with Port Size 1 Inch

About the classical ASCO submerged type Pulse Valve,the pulse valve input end (IN) is connected to the metal tube of the gas storage cylinder, and the output end thereof is connected with the dust blowing box blowing pipe, and the connecting thread is filled with the tetrafluoroethylene raw material tape to be tightly sealed.The Y-type pulse valve is a submerged valve (also known as an embedded valve) that is mounted directly on the air bag for better flow characteristics.

The pressure loss has been reduced, which is suitable for workplaces with low air supply pressure.This type Pulse Valve are instock,If you are interesting,pls contact us without any hesiratioln.

Model No.	QK25
Working Pressure	0.3-0.8mpa’
Environment Temperature	-5~55℃
Relative Humidity	〈85%
Working Medium	Clean Air
Voltage	AC110 AC220 DC24V
Diaphragm Usage	Injection more than 1 million

Other Specifications Can be Available

Air Working Medium ASCO Submergerd Type Pneumatic Pulse Valve QK25 With Port Size 1 Inch 0

Detailed Datas as Follwos for Reference

Air Working Medium ASCO Submergerd Type Pneumatic Pulse Valve QK25 With Port Size 1 Inch 1

Whole Set of Bag Dust Filter System Supply

Air Working Medium ASCO Submergerd Type Pneumatic Pulse Valve QK25 With Port Size 1 Inch 2

The Usage of Pneumatic Pulse Valve :

The electromagnetic pulse valve (also known as the diaphragm valve) is the compressed air "switch" of the pulse bag type dust collector cleaning system. Controlled by the output signal of the pulse controller, the filter bag is sprayed and cleaned row by row (room), so that the resistance of the dust collector is kept within the set range to ensure the dust collector Processing capacity and dust collection efficiency.

The Z-type pulse valve is a right-angle valve with an angle of 90° between the inlet and outlet. It is suitable for the installation link between the air bag and the blow pipe. The air flow is unobstructed and can provide the required cleaning gas pulse.

The Y-type pulse valve is a submerged valve (also known as an embedded valve) that is mounted directly on the air bag for better flow characteristics. The pressure loss has been reduced, which is suitable for workplaces with low air supply pressure.

Preventive Maintenance of Solenoid Valve:

Keep the medium flowing through the pulse valve as smoothly as possible to prevent dust and foreign matter from entering In use, the valve should be run at least once a month to ensure normal opening and closing;

Depending on the medium and operating conditions, it is recommended to periodically check the internal parts of the valve for damage, or excessive wear, thoroughly clean all parts (all valves should be cleaned regularly, the cleaning interval varies according to the medium and operating conditions, in general, If the voltage applied to the coil is correct, then running hysteresis, noise, or excessive leakage indicates that cleaning is required. In extreme cases, valve operation may occur, or the valve may not open and close. When cleaning the valve, it should be cleaned at the same time. Filter or filter)

If you want to know more,pls contact us at once
