| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | BAPC210030051 |
| Minimum Order Quantity: | 200 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 200000 sets per month |
| Product Name: | Pulse Valve Armature | Fitted Pulse Valve Model: | VNP206, VNP306, VNP208, VNP308, VNP408, VNP608, VNP708, VNP212, VNP312, VNP412, VNP214, VNP314, VNP414, VNP614, VNP714, VNP216, VNP416, VNP616, VNP716, VNP220, VNP420, VNP424, VNP620, VNP720 |
|---|---|---|---|
| Plunger Tube Material: | Stainless Steel | Seal Material: | NBR, VITON |
| Ordering Code: | CP1/4 | 1 Set: | 1pc Plunger Tube, 1pc Iron Core, 1pc Spring |
| Highlight: | Mecair Pulse Valve Armature,Mecair Pulse Valve Plunger,Mecair Pulse Valve Armature Plunger |
||
CP1/4 Mecair Dust Collector Pulse Jet Solenoid Valve Armature Plunger
This is CP1/4 solenoid armature for Mecair Pulse Jet Valve VNP206, VNP306, VNP208, VNP308, VNP408, VNP608, VNP708, VNP212, VNP312, VNP412, VNP214, VNP314, VNP414, VNP614, VNP714, VNP216, VNP416, VNP616, VNP716, VNP220, VNP420, VNP424, VNP620, VNP720.
Pulse valves (also called diaphragm valves) are the “switch” for compressed air in the dust clean blowing system of the pulse bag filter. It is used to control the release of air pulses in the cleaning cycle. When the dust collector control board starts the cleaning cycle, it sends an electrical signal to the solenoid valve, and then activates the pulse valve. Inside the pulse valve, the rubber diaphragm opens and closes to release the compressed air stored in the air header. At this time, the air enters the blowing pipe above the filter through the valve, and then enters the filter down to clean the filter bag.
Dimension & Data of Armature, Coil for Mecair Pulse Valve:
|
BRANDO Model
|
BAPC210030051
|
|
Ordeirng Code
|
CP1/4
|
|
Plunger Tube Material
|
Stainless Steel
|
|
Seal Material
|
NBR, VITON
|
|
BRANDO Model
|
BB10230001
|
|
Ordering Code
|
SB3
|
|
Voltage
|
24VDC, 110VAC, 220VAC
(50/60Hz)
|
|
Power
|
10VA, 19VA, 6W, 15W
|
|
Connector
|
DIN 43650 Form A
|
|
Insulation Class
|
F, H
|
Video of Solenoid Armature For Mecair Pulse Valve:
BRANDO Solenoid Valve Armature Production Video:
More Products For Mecair Pulse Valve for you to choose:
|
|
|
|
| Valve Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
