| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | UD-8 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $2 to $5 per pc |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-7 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Product Name: | 2W025-08 / UD-8 Uni-D Type Solenoid Valve | Availability Of Fluid Type: | Water, Air, Light Oil, Gas, Vacuum |
|---|---|---|---|
| Pipe Size: | 1/4'' | Orifice Size: | 2.5mm |
| Valve Type: | 2 Way, Normally Closed (NC) | Action Type: | Direct Acting, Uni-Directional, Zero Differential |
| Valve Body Material: | Brass | Seals Material: | NBR (Nitrile), Option: VITON (FKM) |
| Operating Pressure: | 0 To 101 PSI (for Air, Water), 0 To 72 PSI (for Oil) | Operating Temperature: | Media: -5 To 80°C (NBR Seal), -5 To 120°C (Viton Seal) |
| Highlight: | electric solenoid valve,solenoid pneumatic valve |
||
2W025-08 UD-8 1/4'' UNI-D Type Brass Solenoid Valve Direct Acting Normally Closed 24VDC 110VAC
This 2W025-08 / UD-08 solenoid valve has a port size that is 1/4” inch female threaded. The orifice size is 2.5mm and the CV value is 0.23. This valve is not recommended for gravity fed systems because of the small orifice size. The seal material is NBR, and Viton Rubber is also available.
The coil head is fitted with a wire lead that can easily be connected with your own choice of terminals. The top of the coil features a label that indicates the valve type and specifications. Its response time is very low; in fact, it acts in less than one second, making it a great choice for all types of applications.
This model works best mounted in an upright position with the coil on top. The body features a stamped arrow on the valve body to indication the direction of flow. The valve body is threaded at the base and can quickly be mounted with 5mm machine screws.
Our full range of universal brass solenoid valves are available in various sizes. These valves can be used in both normally open and normally closed positions. Ideal for a wide range of applications. Customers commonly use the UD-8 / 2W025-08 Valve for Water Filters, Ice Makers, Drinking Fountains, Washing Machines, Dishwashers, Dental Tools, Fish Tanks, Beer Brewing, Hydroponics, HVAC and Plumbing.
YouTube video of 2W025-08 UD-8 Electric Solenoid Valve Normally Closed:
Main dimension of 1/4'' 2W025-08 Direct Acting NC Water Solenoid Valve:
Details of 1/4 Inch UD-8 UNI-D Type Normally Closed Solenoid Water Valve:
Specifications of 2W, UD & UW Series 2/2 Way Brass Solenoid Valves:
| Ref No | Model No | Pipe Size | CV | Orifice |
Fluid Temp. (°C) |
Operating Pressure kgf/ cm2 (bar) |
||
| Water | Air | Light oil | ||||||
| UD-6 | 2W025-06 | 1/8'' | 0.23 | 2.5mm | -5°C- +80°C | 0~7 | 0~7 | 0~7 |
| UD-8 | 2W025-08 | 1/4'' | 0.23 | 2.5mm | -5°C- +80°C | 0~7 | 0~7 | 0~7 |
| UD-10 | 2W040-10 | 3/8'' | 0.58 | 4mm | -5°C- +80°C | 0~10 | 0~10 | 0~10 |
| UW-10 | 2W160-10 | 3/8" | 4.5 | 15mm | -5°C- +80°C | 0~5 | 0~7 | 0~5 |
| UW-15 | 2W160-15 | 1/2'' | 4.5 | 15mm | -5°C - +80°C | 0~5 | 0~7 | 0~5 |
| UW-20 | 2W200-20 | 3/4" | 8.6 | 20mm | -5°C- +80°C | 0~5 | 0~7 | 0~5 |
| UW-25 | 2W250-25 | 1" | 12 | 25mm | -5°C- +80°C | 0~5 | 0~7 | 0~5 |
| UW-35 | 2W350-35 | 1-1/4" | 24 | 35mm | -5°C- +80°C | 0~5 | 0~7 | 0~5 |
| UW-40 | 2W400-40 | 1-1/2" | 28 | 40mm | -5°C - +80°C | 0~5 | 0~7 | 0~5 |
| UW-50 | 2W500-50 | 2" | 48 | 50mm | -5°C - +80°C | 0~5 | 0~7 | 0~5 |
Application fields of 2W025-08 / UD-8 Direct Acting Solenoid Valve:
What we can do for you:
Brando has a variety of 2/2 way brass solenoid valves. They have 2 ports (1 inlet and 1 outlet) and 2 electromechanically controlled switching states (open or closed). They are only used to start / stop media flow and are usually closed most often (power on), so if the power fails, the valve will close. They can also be designed as normally open (power off) or bistable (latch).
There are multiple selection criteria from orifice size, connection type, voltage, pressure range, operation, design, certification, sealing materials and housing materials to ensure you have the valve that is right for your application. Our port sizes range from 1/8 inch to 2 inches and can meet the requirements of most applications, but for applications beyond this range, we also serve you. Depending on the wires available in the application, AC or DC voltage coils can be used.
