1261253 1271526 Pulse Valve Repair Kit Diaphragm For Norgren 1" 8296400 3" 8292900

1261253 1271526 Pulse Valve Repair Kit Diaphragm For Norgren 1'' 8296400 3'' 8292900

This 1271526 dipahragm repair kit is use in Norgren 1'' 8296400 and 8292900 pulse valves. Because the diaphragm of pulse valve is a flexible mechanism which needs to open and close frequently to control the air flow, it requires good flexibility and as high sealing as possible. This diaphragm is made of TPE, which has many advantages as following:

1. Good chemical resistance
2. Aging resistance
3. Can be used in a wide temperature range from -40 ℃ to 85 ℃
4. Service life is 4-5 times longer than that of comparable, conven-tional fabric diaphragms.

YouTube video of 1271526 Diaphragm Repair Kit For Norgren Pulse Valve:

Main dimension of 1271526 Norgren Type Diaphragm Valve Repair Kit:

Details of Diaphragm For Norgren 1'' 8296400 3'' 8292900 Pulse Valve:

Available Models of Diaphragm Valve Repair Kits For Norgren Pulse Valves:

Factory Production Pictures of Solenoid Valve Diaphragm Kits:

Diaphragm Features:

1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.

2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.

3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.

4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility

5. EPDM, Viton all available.
