| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | PU225 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Name: | PU225 Solenoid Valve | Working Fluids: | Water, Light Oil, Compressed Air |
|---|---|---|---|
| Port Size: | 3/8'', 1/2'', 1'', 1 1/4'', 1 1/2'' | Orifice Size: | 13, 25, 38 |
| Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC, 380VAC (50/60Hz) | Operation: | Pilot Operated |
| Operation Mode: | 2/2 Way, Normally Closed / Normally Open | Body Material: | Brass |
| Seal Material: | NBR Or VITON, EPDM | Pressure Range: | 0 To 15.0 Bar |
| Highlight: | Shako Solenoid Valve,Shako Solenoid Valves,Solenoid Valve Shako |
||
Shako Type Brass Solenoid Valve 1 1/4'' PU225-012 1 1/2'' PU225-14 220V AC 24V DC
1. PU225 Brass pilot / servo General purpose 2/2 Way normally closed solenoid valve.
2. Port sizes: 3/8" PU225-03, 1/2" PU225-04, 3/4" PU225-06, 1" PU225-08, 1 1/4" PU225-12, 1 1/2" PU225-14, 2" PU225-20, 2 1/2" PU225-24 and 3" PU225-28
3. Port Options: G, BSP, NPT.
4. Construction: Body die cast Brass, stainless steel internals one piece core tube, AISI430F armature and AISI302 springs that extend valve life.
5. Seal options: NBR, EPDM or FKM all metal disc reinforced for longer life.
6. Pressure Range: 0.5 to 10 Bar differential, Max working 15 Bar
7. Voltages: 12vDC, 24vDC, 48vDC, 110vDC, 220vDC or 12vAC, 24vAC, 48vAC, 110vAC, 220vAC, 230vAC, 240vAC, 380vAC and 415vAC
8. PU225 solenoid valves are all 15 Bar pressure, function and leak tested prior to despatch.
9. Includes PU225-03, PU225-04, PU225-06, PU225-08, PU225-12, PU225-14 and PU225-20, PU225-24, PU225-28.
Main Dimension of PU225 Series Brass Solenoid Valve:
Technical Data of PU225 Series Brass Solenoid Valve:
More Solenoid Valves for you to choose:
Brando Factory Production of Brass Solenoid Valves:
As a solenoid valve supplier, BRANDO supplys general purpose solenoid valve for general mediums control. Such as water, air, gas, oil. Offering the cost-effective solution for your projects. Available in brass, stainless steel and PVC material for your projects.
● Size Range: 1/4" to 2" (1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4")
● Voltage: 12 Volt DC, 24 Volt DC, 24 Volt AC, 110 Volt AC, 220 Volt AC
● Pressure: 0-10 bar / 0.3-16 bar
● Temperature: -10℃~180℃
● Material: Brass, Stainless Steel and PVC
● Structure: Direct Acting / Diaphragm / Pilot Operated
● Function: Normally Closed / Normally Open
● Connection Type: Threaded, Flanged, Tri Clamp
● Tolerance: ±10%
