UNI-D Type SUW-20 2S200-20 G3/4" Stainless Steel Solenoid Water Valve DC24V AC220V

UNI-D Type SUW-20 2S200-20 G3/4'' Stainless Steel Solenoid Water Valve DC24V AC220V

Type:SOLENOID VALVES
Place of Origin:Zhejiang, China
Brand Name:Brando
Model Number:2S200-20
Application:General
Temperature of Media:Medium Temperature
Power:Solenoid
Media:Air, Water, Steam, Gas
Port Size:3/4''
Structure:Plug
Orifice size:20.0mm
Function:2/2 Way, Normally Closed
Operation:Direct Acting
Valve body material:Stainless Steel 304
Seals material:NBR (EPDM, VITON Available)
Voltages:DC24V, AC110V, AC220V
Pressure range:0 to 1.0 Mpa
Temperature range:-5 to +100℃

Dimension of 2W/2S Water Solenoid Valve :

Technical Data:

Product Features:
1. UW series is direct, multiplex, connected diaphragm, conductive and normally closed (NC) 2/2 way solenoid valve;

2. Able to be operated directly under low pressure;

3. Availability of fluid type:water, air, light oil;

4. Diaphragm accept for customization NBR, Viton, Silicone and EPDM.
