| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | ADK11-15 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Power: | Solenoid | Media: | Air Water Oil Gas |
|---|---|---|---|
| Port Size: | 1/2'' | Function: | 2/2 Way, Normally Closed / Normally Open |
| Operation: | Direct Acting | Body Material: | Stainless Steel |
| Seal Material: | NBR, EPDM, FKM, Si | Medium Temperature: | -10 To +60℃ |
| Electrical Connector: | DIN 43650 Connector, Wire Leads | Voltages: | 12V DC, 24V DC, 24V DC, 110V AC, 220V AC |
| Highlight: | CKD Type Solenoid Valve,Normally Closed Solenoid Valve |
||
1/2'' CKD Type Normally Closed Solenoid Valve Stainless Steel General Purpose Valve ADK11-15
Power:Solenoid
Media:Air, Water, Oil, Gas
Port Size:1/8'' to 2''
Function:2/2 Way, Normally Closed / Normally Open
Operation:Direct Acting
Body Material:Stainless Steel
Seal Material:NBR, EPDM, FKM, Si
Medium Temperature:-10 to +60℃
Electrical Connector:DIN 43650 Connector, Wire Leads
Voltages:12V DC, 24V DC, 24V DC, 110V AC, 220V AC
Orifice Size (mm):1.5, 2, 3, 3.5, 4, 5, 7, 10
Dimension of CKD Type ADK11 Series Solenoid Valve:
| Model No. | A | B | C | D | E | F | G |
| ADK11-15A-02C | 71 | 27(29) | 14.5 | 75.5 | 102 | 50 | Rc1/2 |
| ADK11-20A-02C | 80 | 32(35) | 17.5 | 79 | 108.5 | 60 | Rc3/4 |
| ADK11-25A-02C | 90 | 41(45) | 21.5(22.5) | 84.5 | 118(119) | 71 | Rc1 |
Technical Data:
| Descriptions | Standard Specifications | Optional Specifications |
| Working Fluid | Air/low vacuum (1.33 x 103 Pa (abs))/water/kerosene/oil (50mm2 /s or less) |
Hot Water |
| Working pressure differential MPa | 0 to 1.0 (refer to max. working pressure differential in individual specifications.) | |
| Max. working pressure MPa | 2 (≈290 psi, 20 bar) | |
| Proof pressure (water pressure) MPa | 4 (≈580 psi, 40 bar) | |
| Fluid temperature (*1) °C | -10 (14°F) to 60 (140°F) | -10 (14°F) to 90 (194°F) |
| Ambient temperature °C | -10 (14°F) to 60 (140°F) | |
| Thermal class | Class 130 (B) | Class 180 (H) |
| Atmosphere | Place free of corrosive gas and explosive gas | |
| Valve structure | Pilot kick poppet, diaphragm drive | |
| Valve seat leakage (*2) cm3 /min(ANR) | 1 or less (air) | |
| Mounting orientation | Unrestricted | |
| Body/seal material | Bronze/nitrile rubber | Bronze/ethylene propylene rubber |
Brando Factory Production of Solenoid Valves:
Product Features:
1. ADK11 series is direct, multiplex, connected diaphragm, conductive and normally closed (NC) 2/2 way solenoid valve;
2. Able to be operated directly under low pressure;
3. Availability of fluid type:water, air, light oil;
4. Diaphragm accept for customization NBR, FKM, Silicone and EPDM.
