Yuken Type Hydraulic Solenoid Valve Coil

Eaton Vickers Type Hydraulic Solenoid Valve Coil

Specification:
1. Voltage: 12VDC, 24VDC, 110VAC, 120VAC, 220VAC, 240VAC
2. Application: For Yuken hydraulic solenoid valve
3. Coil No: D12, D24, D100, A100, A120, A200, A240, R100, R200, RQ100
4. Connector type: DIN 43650A, 2 Pins (Plug In Type)

5. Valve Type: Yuken directional control valve, DSG-01 series, DSG-03 series
6. Valve Sizes: 6, 10.

Yuken solenoid coil, also known as Yuken valve coil, or Yuken coil for directional valves. Yuken solenoid coil is the main part of Yuken hydraulic solenoids. The hydraulic solenoid is the actuator of Yuken DSG directional valves. A complete hydraulic solenoid is consist of a solenoid coil and a solenoid tube assembly.

Solenoid coil is a hollow bobbin winding with a bunch of copper wires. When the solenoid coil has been electrified, the copper wires will create a magnetic field, and the magnetic field makes the plunger in solenoid tube move and triggers the operation of the directional valves.

Features:

1. The Yuken solenoid coil is encapsulated with high quality glass-filled nylon, which has better intensity, rigidity, thermostability, etc.
2. The solenoid bobbin of Yuken solenoid coil uses the quality material with 30% glass-filled thermoplastic polyester, which can enhance the thermostability of the solenoid bobbins.
3. Multiple choices of solenoid copper wires, Kaidi provides solenoid coils with class F, class H, class N copper wires, and the IP grade can reach IP65 and IP67.

Dimension & Data of Hydraulic Solenoid Valve Coil:

Picture	Dimension	Model	BB23660411
		Voltage	12VDC, 24VDC, 110VAC, 220VAC
		Power	42W
		Connector Type	DIN43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB23660407
		Voltage	12VDC, 24VDC, 110VAC, 220VAC
		Power	30W
		Connector Type	DIN 43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB20151537
		Voltage	12VDC, 24VDC, 110VAC, 220VAC
		Power	30W
		Connector Type	2 Pins (Plug In Type)
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB26149508
		Voltage	110VAC, 220VAC
		Power	35W
		Connector Type	2 Pins (Plug In Type)
		Insulation Class	H
		Protection Class	IP67

Brando Factory Production of Solenoid Valve Coil:

Other hydraulic solenoid valve coil fo you to choose:

Vickers Type Hydraulic Solenoid Valve Coil:

Bosch Rexroth Type Hydraulic Solenoid Valve Coil:

Advantages of our hydraulic solenoid coil as follows:

1. A variety of integrated connections and wires ideas available.

2. The advanced design of one-piece and shell encapsulated, and hydraulic solenoid coil meets the most stringent environmental requirements for mobile and industrial applications.

3. IP69K Environmental Protection: IP69K can prevent dash and high-pressure spray entering the solenoid coil. IP69K test is focused on the rating protection against high-pressure spray, high-temperature liquid and close nozzle distance from the enclosure surface. IP69K is standard on coils with MetriPac or Deutsch, integrated connectors.

4. Our hydraulic solenoid coil can replace all current Eaton Vickers coils used on D Frame and Shell type coils. Compact coil applies for most 8, 10, 12, 16 and 20 series valves.

5. No additional water/weather proofing is needed.

6. The design of steel shell encapsulated provides protection against physical and environmental damage.
