Bosch Rexroth Type Hydraulic Solenoid Valve Coil

Bosch Rexroth Type Hydraulic Solenoid Valve Coil

Specification:

1. Voltage: 12VDC, 24VDC, 110VAC, 220VAC
2. Power: 20W, 25W, 26W, 28W, 30W, 33W, 37W, 46W
3. Connector Type: DIN 43650A, DEUTCH, AMP, Flying Leads, Plug In Type
3. Valve Type: Rexroth directional control valve
4. Valve Sizes: NG6, NG10.

Rexroth solenoid coil is also known as Rexroth solenoid valve coil or Rexroth coil. The solenoid coil works as an actuator based on electromagnetic induction principle. When the flowing of electricity passes through a wire, it creates an electromagnetic field around this wire. The wire in the electromagnetic field will develop the electromagnetic interaction on other wires in the range of electromagnetic field. The interaction works on the wire itself called self-induction, which means the wire creates electricity and turns it into the electromagnetic field on its own. The electromagnetic field created by the self-induction has further influence on the current in the wire. There is a relative concept named mutual induction, which means the wire have electromagnetic interaction on other wires around the electromagnetic field.

Dimension & Data of Hydraulic Solenoid Valve Coil:

Picture	Dimension	Model	BB23150508
		Voltage	12VDC, 24VDC, 110VAC, 220VAC
		Power	30W
		Connector Type	DEUTCH
		Insulation Class	F
		Protection Class	IP67

Picture	Dimension	Model	BB23660407
		Voltage	12VDC, 24VDC, 110VAC, 220VAC
		Power	46W
		Connector Type	DIN 43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB22046009
		Voltage	110VAC, 220VAC
		Power	28W
		Connector Type	DIN43650A
		Insulation Class	H
		Protection Class	IP65

Picture	Dimension	Model	BB22046010
		Voltage	110VAC, 220VAC
		Power	28W
		Connector Type	2 Pins (Plug In Type)
		Insulation Class	F
		Protection Class	IP65

Brando Factory Production of Solenoid Valve Coil:

Other hydraulic solenoid valve coil fo you to choose:

Vickers Type Hydraulic Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil:

Advantages of our hydraulic solenoid coil as follows:

1. A variety of integrated connections and wires ideas available.

2. The advanced design of one-piece and shell encapsulated, and hydraulic solenoid coil meets the most stringent environmental requirements for mobile and industrial applications.

3. IP69K Environmental Protection: IP69K can prevent dash and high-pressure spray entering the solenoid coil. IP69K test is focused on the rating protection against high-pressure spray, high-temperature liquid and close nozzle distance from the enclosure surface. IP69K is standard on coils with MetriPac or Deutsch, integrated connectors.

4. Our hydraulic solenoid coil can replace all current Eaton Vickers coils used on D Frame and Shell type coils. Compact coil applies for most 8, 10, 12, 16 and 20 series valves.

5. No additional water/weather proofing is needed.

6. The design of steel shell encapsulated provides protection against physical and environmental damage.
