Vickers Type Hydraulic Solenoid Coil 02-124661 12VDC 02-124662 24VDC 30W

Vickers Type Hydraulic Solenoid Coil 02-124661 12VDC 02-124662 24VDC 30W

As a professional coil manufacturer and supplier in China. We also provide solenoid coils specifically for hydraulic valves. Can be installed on various types of hydraulic solenoid valves.Our main voltage is 12v, 24v, 110v and 220v AC and DC hydraulic coils. Of course, we can also customize the coil for you according to your needs.

Specifications of Customized Hydraulic Solenoid Coils
1. Standard Voltage: DC:12V / 24V,AC:24V / 220V / 380V
2. Coil Insulation: Class F/ H/ N, others on request.
3. Connector type: DIN43650, Deutsch, Amp, Flying Leads, Plug In Type, etc.
4. Application: Can be installed in various types of hydraulic valves

Dimension & Data of Hydraulic Solenoid Valve Coil:

Picture	Dimension	Model	BB23660407
		Ref. No	02-124661 (12V) 02-124662 (24V)
		Voltage	12VDC, 24VDC
		Power	30W
		Connector Type	AMP
		Insulation Class	F
		Protection Class	IP67

Picture	Dimension	Model	BB23660411
		Ref. No	507847 (12V) 507848 (24V)
		Voltage	12VDC, 24VDC
		Power	30W
		Connector Type	DIN43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB23745310
	​	Ref. No	02-101732, 02-101731
		Voltage	110VAC, 220VAC
		Power	17W
		Connector Type	Flying Leads
		Insulation Class	H
		Protection Class	IP67

Picture	Dimension	Model	BB23745309
		Ref. No	02-101727 (220V) 02-101726 (110/120V)
		Voltage	110VAC, 220VAC
		Power	17W
		Connector Type	DIN43650A
		Insulation Class	H
		Protection Class	IP65

Brando Factory Production of Solenoid Valve Coil:

Other hydraulic solenoid valve coil fo you to choose:

Bosch Rexroth Type Hydraulic Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
