Vickers Type Hydraulic Solenoid Valve Coil 02-365539 12VDC 30W

Vickers Type Hydraulic Solenoid Valve Coil 02-365539 12VDC 30W

Brando hydraulic solenoid coils for directional and proportional valves ensure the correct and safe supply of the corresponding control current. Practically all coil voltages are available from stock in a large selection of plug variations. Special voltages and special coil designs are available upon request. The solenoid coil is available in standard voltages of 12, 24, 110, 120, 220 and 240 volts, depending on the power required for the solenoid valve. Thanks to its exceptional winding, the coil is very small has a high power output.

Solenoids and coils are used to convert electrical energy to the mechanical force used to shift valve components to control flow or pressure. The coil and solenoid are separate components. The solenoid is the tube that contains the armature and pole piece. The coil fits the solenoid and contains multiple wraps of copper magnet wire. With switching solenoid valves, the coil is either energized or deenergized. With electro-proportional solenoid valves, the power to the coil is controlled with a current control device, a proportional amplifier. The same coil can be used for both switching solenoids and proportional solenoids.

Dimension & Data of Hydraulic Solenoid Valve Coil:

Picture	Dimension	Model	BB23660412
	​	Ref. No	02-365539
		Voltage	12VDC, 24VDC
		Power	30W
		Connector Type	DEUTCH
		Insulation Class	F
		Protection Class	IP67

Picture	Dimension	Model	BB23660407
		Ref. No	02-124661 (12V) 02-124662 (24V)
		Voltage	12VDC, 24VDC
		Power	30W
		Connector Type	AMP
		Insulation Class	F
		Protection Class	IP67

Picture	Dimension	Model	BB23660411
		Ref. No	507847 (12V) 507848 (24V)
		Voltage	12VDC, 24VDC
		Power	30W
		Connector Type	DIN43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB23660513
		Ref. No	508173 (24VDC) 02-324068 (24VDC) 508169 (110V/120V)
		Voltage	12VDC, 24VDC, 110VAC, 220VAC
		Power	30W
		Connector Type	Flying Leads
		Insulation Class	F
		Protection Class	IP67

Brando Factory Production of Solenoid Valve Coil:

Other hydraulic solenoid valve coil fo you to choose:

Bosch Rexroth Type Hydraulic Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
