MPM 18mm M3 x 28 3 Pin DIN 43650 Form A Black Solenoid Coil Connector

MPM 18mm M3 x 28 3 Pin DIN 43650 Form A Black Solenoid Coil Connector

Solenoid valve A-type solenoid valve plug connector-2+PE/3+PE; pin spacing is 18mm, round or square base, widely used in hydraulic valve plug connectors, solenoid valve plug connectors, proportional valve plugs Connector, pressure sensor plug and transmitter plug, temperature sensor plug and other fields.

Junction box, also known as connectors, widely used in hydraulic, pneumatic, electrical and other industies, as the solenoid valve coil and other parts of the external control of electrical connection.

Dimension of Soelnoid Valve Connector:

DIN 43650A Connector:

Dimension	DIN Type	DIN 43650 Form A
	Distance	18mm
	Form	2+1GND, 3+1GND
	Protection Class	IP65
	Working Voltage	AC380V, DC300V
	Fixing Screw	M3x28
	Nomical Current	10A
	Contact Resistance	≤5mΩ
	Max Conductor Section	3x1.5mm²

DIN43650B Connector:

Dimension	DIN Type	DIN 43650 Form B
	Distance	11mm
	Form	2+1GND, 3+1GND
	Protection Class	IP65
	Working Voltage	AC380V, DC300V
	Fixing Srew	M3x30
	Nomical Current	10A
	Cntact Resistance	≤5mΩ
	Max Conductor Section	3x1.5mm²

DIN43650C Connector:

Dimension	DIN Type	DIN 43650 Form C
	Distance	9.4mm
	Form	2+1GND, 3+1GND
	Protection Class	IP65
	Working Voltage	AC380V, DC300V
	Fixing Screw	M3x25
	Nomical Current	10A
	Cntact Resistance	≤5mΩ
	Max Conductor Section	3x1.5mm²

More Solenoid Connectors:

DIN43650A	DIN43650B	DIN43650C

Product Features:

The connectors is used extensively to provide electrical connection in a wide range of applications.
The most common application for connectors is in conjunction with pneumatic, hydraulic or electromagnetic devices, including solenoid valves.
Other applications include, for example, pressure transducers, proximity switches, level sensors, limit switches and low energy motors.
BRANDO company manufactures an extensive and comprehensive range of connectors with standard options including for example LED illuminated devices as well as VDR, diodes or transil diodes (with or without illuminated device) to offer protection against over voltage peaks.
Our connectors offer protection from dust and water (IP65 or IP67 on specific request) when correctly installed with screw and gasket which are supplied together with the connector.
