| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA45DD |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Dresser Nut Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 1-1/2''Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 2 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| Highlight: | CA45DD010-305 Pulse Jet Valve,CA45DD000-301 Pulse Jet Valve,CA45DD Dust Collector Valve |
||
CA45DD CA45DD010-305 CA45DD000-301 1.5'' Inch Pulse Valve With Dresser Nut
Pulse Jet Valve play an important role in dust collector. A dust collector is a system used to enhance the quality of air released from industrial and commercial processes by collecting dust and other impurities from air or gas. Designed to handle high-volume dust loads, a dust collector system consists of a blower, dust filter, a filter-cleaning system, and a dust receptacle or dust removal system. It is distinguished from air purifiers, which use disposable filters to remove dust.
Maintenance Kits :
| Model | Nitrile | Viton | Low Temperature -60°C (–76°F) MIN. | Includes |
| CA/RCA25DD | K2501 | K2503 | K2504 | Diaphragm kits include main and secondary diaphragms(where required) and all springs |
Technical Data of Goyen Pulse Jet Valve:
|
Model
|
CA20DD
|
CA25DD
|
CA45DD
|
|
|
Nominal Size
|
20
|
25
|
45
|
|
|
Port size
|
mm
|
20
|
25
|
40
|
|
in
|
3/4
|
1
|
1 1/2
|
|
|
Number of Diaphragms
|
1
|
1
|
2
|
|
|
Flow
|
Kv
|
12
|
20
|
44
|
|
Cv
|
14
|
23
|
51
|
|
|
Pressure (Psi)
|
5 to 125
|
5 to 125
|
5 to 125
|
|
|
Temperature℃
|
NBR
|
-40 to 82
|
-40 to 82
|
-40 to 82
|
|
FKM
|
-29 to 232
|
-29 to 232
|
-29 to 232
|
|
Main Dimension:
CA RCA Series Pulse Jet Valve For Dust Collector System:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Mr. Brandon Bao
Tel: 86-13454729544
Fax: 86-574-83879820
