CA50MM 2'' Inch Submerged Goyen Type Dust Collector Pulse Jet Valve

CA50MM 2'' Inch Submerged Goyen Type Dust Collector Pulse Jet Valve

Installation:
1. MM valves are installed through the tank;
2. To avoid any potential operational problems it is preferable that the valves are not mounted underneath the tank where condensation may collect. All O-rings should be coated with a siliconebased lubricant or similar.
3. Dresser nut seals where used are a pressure seal only, not a structural component. Do not rely on dresser seals to retain either the tanks or blowtubes. Tanks and blowtubes must be independently restrained.
4. Tighten dresser nuts to 20 Nm (15 ftlbs) max.
5. Tighten pipe outlets to 20 Nm (15 ftlbs).
6. Make electrical connections to solenoid or connect RCA pilot port to pilot valve (RCA valves only).
7. Ensure compressed-air supply is dry and free from oil and dirt.
8. Check all cleaning system components are secure before applying pressure.
9. Apply moderate pressure and check for leaks.
10. Fully pressurise system.
11. Test fire and listen for proper actuation and crisp pulse noises.

Technical Data of Goyen Pulse Jet Valve:

Main Dimension:

CA RCA Series Pulse Jet Valve For Dust Collector System:
