| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA89MM |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Submerged Type Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 3-1/2'' 3.5'' Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 2 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| Highlight: | Manifold Flat Mount Pulse Valve,Bag Filter Pulse Valve,CA89MM 3.5 Inch Diaphragm Valve |
||
CA89MM Manifold Flat Mount 3.5'' 3-1/2'' Inch Bag Filter Pulse Valve
The electromagnetic pulse valve can be divided into three types:
a) Right-angle electromagnetic pulse valve: Diaphragm valve with valve body inlet and outlet at right angles, directly controlled by electrical signals;
b) Straight-through electromagnetic pulse valve: Diaphragm valve with valve body inlet and outlet at 180 degrees, directly controlled by electrical signals;
c) Submerged electromagnetic pulse valve: The diaphragm valve whose valve body air inlet is submerged in the air bag and is directly controlled by the electric signal.
In addition to the conventional three solenoid valves, there is a large-caliber ultra-low pressure electromagnetic pulse valve for rotary injection blowing.
The electromagnetic pulse valve is available in 3/4 '', 1 '', 1-1 / 2 '', 2 '', 2-1 / 2 '', 3 '', 4 ''. Bag dust collector is used.
Technical Data of Goyen Pulse Jet Valve:
|
Model No
|
CA25MM
|
CA40MM
|
CA50MM
|
CA62MM
|
CA76MM
|
CA102MM
|
||
|
Nominal Size
|
25
|
40
|
50
|
62
|
76
|
102
|
||
|
Port Size
|
mm
|
25
|
40
|
50
|
62
|
76
|
102
|
|
|
inch
|
1''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
3 1/2''
|
4''
|
|
|
Pressure Range
|
0.3 to 0.8MPa
|
|||||||
|
Temp. Range
|
Nitrile seals
|
-40 to 82℃
|
||||||
|
Viton seals
|
-29 to 232℃
|
|||||||
Main Dimension:
CA RCA Series Pulse Jet Valve For Dust Collector System:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
