| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | G353A041 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Right Angle Type Diaphragm Valve | Power: | Pneumatic |
|---|---|---|---|
| Media: | Air | Port Size: | 3/4'' Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 1 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| Highlight: | Right Angle Diaphragm Valve,G353A041Diaphragm Valve,G353A041 Dust Collector Valve |
||
G353A041 Right Angle 3/4'' Inch Remote Pulse Jet Diaphragm Valve
Installation
1. The valves can be mounted in any position without affecting operation
2. Threaded pipe connection is: G = G (ISO 228/1) or compression fittings
3. When connecting piping or tubing to the G1/8 connection in the valve bonnet, the remote ASCO pilot valve should be mounted as close as possible to the main pulse valve. Connection tubing lengths of 3 meter or less have little effect on the pulse response. Installations with over 3 meter of tubing must be tested under actual operating conditions. Tubing with Φ 6 mm O.D. is recommended for all installations
4. For compression fitting types tightness is achieved by the compressed gasket on the blow tube
5. Other pipe threads are available on request
6. Installation/maintenance instructions are included with each valve
7. Spare parts kit and replacement coils are available
Technical Data of ASCO Pulse Jet Valve:
Main Dimension:
353 Series Pulse Jet Valve For Dust Collector System:
