| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | SCG353A050 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Right Angle Type Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 2'' Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 2 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| Highlight: | SCG353A050 2'' Inch Pulse Jet Valve,Clean Air Pulse Jet Valve,ASCO Type SCG353A050 |
||
SCG353A050 2'' Inch Bag Filter Clean Air Right Angle Pulse Jet Valve
Construction:
Body: Aluminum Alloy
Core Tube:Stainless Steel
Core and Plugnut:Stainless Steel
Core Spring: Stainless Steel
Seals & Diaphragm: NBR(common, all available)
Solenoid Coil : Copper
Installation :
The valves can be mounted in any position without affecting operation
Threaded pipe connection is G (ISO 228/1) or compression fitting
For compression fitting types tightness is achieved by the compressed gasket on the blow tube
The use of the rubber gaskets as sealing members will allow a slight misalignment in piping when using compression fittings
Other pipe threads are available on request
Installation/maintenance instructions are included with each valve
Spare parts kits and replacement coils are available
Technical Data of ASCO Pulse Jet Valve:
|
Model No
|
SCG353A043
|
SCG353A044
|
SCG353A047
|
SCG353A050
|
SCG353A051
|
|
Port Size
|
G3/4''
|
G1''
|
G1-1/2''
|
G2''
|
G2-1/2''
|
|
Nominal Size
|
φ20mm
|
φ25mm
|
φ40mm
|
φ50mm
|
φ62mm
|
|
Working Pressure
|
0.3 to 0.8MPa
|
||||
|
Environment Temperature
|
-5 to +55℃
|
||||
|
Relative Humidity
|
≤85%
|
||||
|
Operating Medium
|
Dry clean compressed air
|
||||
|
Service Life
|
Over one million times
|
||||
|
Voltages
|
AC24V, AC110V, AC220V, DC24V
|
||||
Main Dimension:
353 Series Pulse Jet Valve For Dust Collector System:
