| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 3V210-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Fluids: | Air (to Be Filtered By 40 μ M Filter Element) | Acting: | Internal Pilot Or External Pilot |
|---|---|---|---|
| Valve Type: | 3 Way 2 Position | Port Size: | 1/4'' |
| Pressure Range: | 0.15 To 0.8MPa | Max Pressure Resistance: | 1.5MPa |
| Body Material: | Aluminum Alloy | Voltage: | 12VDC, 24VDC, 110VAC, 220VAC |
| Highlight: | 3V210-08-NC Solenoid Valve,3V210-08-NO Solenoid Valve,3V210-08 Airtac |
||
3V210-08 Airtac Type Pneumatic Solenoid Valve 3V210-08-NC 3V210-08-NO
3 way 2 position pneumatic solenoid valves consist of three ports connected through passages within a valve body. The valves pressurize and exhaust one outlet port to control a single-acting cylinder, or pilot another valve. Three-way valves direct pressurized air to the cap-end side of the cylinder. 3/2 Way pneumatic solenoid valves are suitable for several tasks: driving pneumatic actuators, blow-off, pressure release and vacuum applications.
Technical Data of 3V200 Series Pneumatic Solenoid Valves:
| Model No |
3V210-06 |
3V220-06 |
3V210-08 |
3V220-08 |
| Fluid | Air (to be filtered by 40 μm filter element) | |||
| Port Size | In=Out=1/8'' | In=Out=1/4'' | ||
| Orifice Size |
14.0mm² (Cv=0.78) |
16.0mm² (Cv=0.89) |
||
| Valve Type | 3 Way 2 Position | |||
| Operating Pressure | 0.15 to 0.8MPa (21 to 114 PSI) | |||
| Proof Pressure | 1.5MPa (215PSI) | |||
| Temperature (℃) | -20 to +70 | |||
| Body Material | Aluminum Alloy | |||
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | |||
| Coil Protection Class | IP65 | |||
| Activating Time | 0.05 second and below | |||
Dimension of 3V210-08 Pneumatic Solenoid Valve:
Production Video of Pneumatic Solenoid Valves:
