| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 3V310-10 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Fluids: | Air (to Be Filtered By 40 μ M Filter Element) | Acting: | Internal Pilot Or External Pilot |
|---|---|---|---|
| Valve Type: | 3 Way 2 Position | Port Size: | 3/8'' |
| Pressure Range: | 0.15 To 0.8MPa | Max Pressure Resistance: | 1.5MPa |
| Body Material: | Aluminum Alloy | Voltage: | 12VDC, 24VDC, 110VAC, 220VAC |
| Highlight: | 3V310-10 Solenoid Valve,Pneumatic Solenoid Valve 3 Way,3V310-10 Airtac |
||
3V310-10 Airtac Type Pneumatic Solenoid Valve 3 Way 220VAC 24VDC
Working Principle:
Normally Close 3 Way Pneumatic Solenoid Valve
When unactuated, block inlet flow and connect the outlet port to the exhaust port. When actuated, the inlet port is connected to the outlet port and the exhaust port is blocked.
Normally Open 3 Way Pneumatic Solenoid Valve
When unactuated, pass inlet flow to the outlet and block the exhaust port. When actuated, inlet flow is blocked and the outlet port is connected to the exhaust port.
Technical Data of 3V300 Series Pneumatic Solenoid Valves:
| Model No |
3V310-08 |
3V320-08 |
3V310-10 |
3V320-10 |
| Fluid | Air (to be filtered by 40 μm filter element) | |||
| Port Size | In=Out=1/4'' | In=Out=3/8'' | ||
| Orifice Size |
25.0mm² (Cv=1.39) |
30.0mm² (Cv=1.67) |
||
| Valve Type | 3 Way 2 Position | |||
| Operating Pressure | 0.15 to 0.8MPa (21 to 114 PSI) | |||
| Proof Pressure | 1.5MPa (215PSI) | |||
| Temperature (℃) | -20 to +70 | |||
| Body Material | Aluminum Alloy | |||
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | |||
| Coil Protection Class | IP65 | |||
| Activating Time | 0.05 second and below | |||
Dimension of 3V310-10 Pneumatic Solenoid Valve:
Production Video of Pneumatic Solenoid Valves:
