| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4M220-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Valve Type: | 5 Way 2 Position | Port Size: | In=Out=1/4'' |
|---|---|---|---|
| Pressure Range: | 0.15 To 0.8MPa (21 To 114PSI) | Max Pressure Resistance: | 1.5MPa (215PSI) |
| Body Material: | Aluminum Alloy | Max. Frequency: | 5 Cycle / Second |
| Voltages: | 220V AC, 110V AC, 24V AC, 24V DC, 12V DC | ||
| Highlight: | 5 Way 2 Position Namur Solenoid Valve,Airtac Solenoid Valve,4M220-08 Airtac |
||
4M220-08 Airtac Type Namur Solenoid Valve 5 Way 2 Position
Combination 3 way and 4 way, 3/2 - 5/2 solenoid valve that directly mounts to all NAMUR interface actuators. Standard features include a manual override and safety position by mechanical spring. The solenoid pilots both spring return and double acting actuators. It is available in standard, explosion proof, or Atex.
NAMUR interface, the NAMUR soenoid valve has anodized aluminum body, stainless steel spool, and brass internal parts. Spring return allows fail-safe operation in case of power loss, and screened exhaust nut protects valve function during outdoor use. Multiple solenoid valves can be placed together on a valve manifold.
Data of NAMUR Pneumatic Solenoid Valves:
| Model No |
4M110-M5 4M120-M5 |
4M110-06 4M120-06 |
4M210-06 4M220-06 |
4M210-08 4M220-08 |
4M310-08 4M320-08 |
4M310-10 4M320-10 |
| Fluid | Air (to be filtered by 40 μm filter element) | |||||
| Port Size | In=Out=M5 | In=Out=1/8'' | In=Out=1/8'' | In=Out=1/4'' | In=Out=1/4'' | In=Out=3/8'' |
| Orifice Size |
5.5mm² (Cv=0.31) |
12.0mm² (Cv=0.67) |
14.0mm² (Cv=0.78) |
16.0mm² (Cv=0.89) |
25.0mm² (Cv=1.40) |
30.0mm² (Cv=1.67) |
| Valve Type | 5 Way 2 Position | |||||
| Operating Pressure | 0.15 to 0.8MPa (21 to 114 PSI) | |||||
| Proof Pressure | 1.5MPa (215PSI) | |||||
| Temperature (℃) | -20 to +70 | |||||
| Body Material | Aluminum Alloy | |||||
| Max. Frequency | 5 Cycle / Second | 4 Cycle / Second | ||||
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | |||||
| Coil Protection Class | IP65 | |||||
| Activating Time | 0.05 second and below | |||||
Dimension of 4M220-08 Namur Solenoid Valve:
Production Video of Pneumatic Solenoid Valve:
More Pneumatic Products for you to choose:
2/2 Way 3/2 Way 5/2 Way, Single Solenoid 5/2 Way, Double Solenoid 5/3 Way, Double Solenoid
Solenoid Operator Manifold Silencer Pneumatic Hose Fittings
