| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4M310-10 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Valve Type: | 5 Way 2 Position | Port Size: | In=Out=3/8'' |
|---|---|---|---|
| Pressure Range: | 0.15 To 0.8MPa (21 To 114PSI) | Max Pressure Resistance: | 1.5MPa (215PSI) |
| Body Material: | Aluminum Alloy | Max. Frequency: | 5 Cycle / Second |
| Voltages: | 220V AC, 110V AC, 24V AC, 24V DC, 12V DC | ||
| Highlight: | Namur Interface Solenoid Valve,Solenoid Valve 4M310-10,Airtac Namur Valve |
||
Namur Interface Solenoid Valve 4M310-10 Airtac Type 24V DC 220V AC
The Namur interface enables simple field mounting of the economy Namur solenoid to the pneumatic actuator. It is supplied with an easy to fit change-over fittings to adapt between 5/2 and 3/2 functions for double acting or single acting actuators.
Manufactured in aluminium alloy, the economy solenoid offers good resistance to mildly corrosive atmospheres. Standard IP65 coil options cover the normal voltages and are supplied with a connecting DIN plug. A screwdriver operated manual override is provided. The economy Namur solenoid is suitable for use in safe areas only. For Ex rated Namur solenoids, contact us.
Data of NAMUR Pneumatic Solenoid Valves:
| Model No |
4M110-M5 4M120-M5 |
4M110-06 4M120-06 |
4M210-06 4M220-06 |
4M210-08 4M220-08 |
4M310-08 4M320-08 |
4M310-10 4M320-10 |
| Fluid | Air (to be filtered by 40 μm filter element) | |||||
| Port Size | In=Out=M5 | In=Out=1/8'' | In=Out=1/8'' | In=Out=1/4'' | In=Out=1/4'' | In=Out=3/8'' |
| Orifice Size |
5.5mm² (Cv=0.31) |
12.0mm² (Cv=0.67) |
14.0mm² (Cv=0.78) |
16.0mm² (Cv=0.89) |
25.0mm² (Cv=1.40) |
30.0mm² (Cv=1.67) |
| Valve Type | 5 Way 2 Position | |||||
| Operating Pressure | 0.15 to 0.8MPa (21 to 114 PSI) | |||||
| Proof Pressure | 1.5MPa (215PSI) | |||||
| Temperature (℃) | -20 to +70 | |||||
| Body Material | Aluminum Alloy | |||||
| Max. Frequency | 5 Cycle / Second | 4 Cycle / Second | ||||
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | |||||
| Coil Protection Class | IP65 | |||||
| Activating Time | 0.05 second and below | |||||
Dimension of 4M310-10 Namur Solenoid Valve:
Production Video of Pneumatic Solenoid Valve:
More Pneumatic Products for you to choose:
2/2 Way 3/2 Way 5/2 Way, Single Solenoid 5/2 Way, Double Solenoid 5/3 Way, Double Solenoid
Solenoid Operator Manifold Silencer Pneumatic Hose Fittings
