| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4V410-15 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Type: | 5/2 Way, Single Solenoid | Port Size: | In=Out=Exhaust=1/2'' |
|---|---|---|---|
| Pressure Range: | 0.15 To 0.8MPa (21 To 114PSI) | Max Pressure Resistance: | 1.5MPa (215PSI) |
| Body Material: | Aluminum Alloy | Max. Frequency: | 3 Cycle / Second |
| Highlight: | Air Pneumatic Solenoid Valve,Pneumatic Solenoid Valve 220V,4V410-15 Airtac |
||
4V410-15 Airtac Type Air Pneumatic Solenoid Valve 220V 5/2 Way 1/2''
This 4V410-15 solenoid valve is a 5/2 way pneumatic valve which means it has 5 ports; 2 exhaust ports through which air is regulated as it flows out, 2 power ports that power the system, 1 supply port for the inlet of air pressure, and 2 flow positions. This valve is made with an aluminum alloy and has an aperture of 1/2''.
BRNADO pneumatic valves offer reliability, low power consumption, and have a long life. They are have prewired connections that makes installation, maintenance, and control simple.
Technical Data of 4V400 Series Pneumatic Solenoid Valves:
|
Model
|
4v410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
|
Fluid
|
Air (to be filtered by 40 μ m filter element)
|
||||
|
Acting
|
Internal Pilot or External Pilot
|
||||
|
Port Size
|
In=Out=Exhaust=1/2''
|
||||
|
Orifice Size
|
50.00 mm² (Cv=2.79)
|
30.00 mm² (Cv=1.68)
|
|||
|
Valve Type
|
5 Way 2 Position
|
5 Way 3 Position
|
|||
|
Operating Pressure
|
0.15~0.8 MPa (21~114 psi)
|
||||
|
Proof
|
1.5 MPa (215 psi)
|
||||
|
Temperature ℃
|
-20 to 70
|
||||
|
Material of Body
|
Aluminum Alloy
|
||||
|
Max. Frequency
|
3cycle/sec
|
||||
Dimension of 4V410-15 Pneumatic Solenoid Valve:
Product video of 4V410-15 Pneumatic Solenoid Valve:
Production Video of Pneumatic Solenoid Valve:
