| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | DNC |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 work days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Series: | Piston Rod Cylinder | Bore Size (mm): | 32, 40, 50, 63, 80, 100, 125 |
|---|---|---|---|
| Standard Stroke (mm): | 25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800, 900, 1000 | Acting Type: | Double Acting |
| Operating Pressure Range: | 0.15 To 1.0 MPa | Proof Pressure: | 1.5 MPa |
| Highlight: | Festo Air Cylinder,Piston Rod Pneumatic Cylinder,Festo DNC-32-50-PPV-A |
||
Festo Type DNC-32-50-PPV-A Piston Rod Pneumatic Air Cylinder ISO 15552
Standard pneumatic cylinders allow standardized machine layouts and guarantee high availability in combination with a wide range of mounting options. The range extends from Mini and round cylinders (Ø8-25 mm, ISO 6432) via short-stroke and compact cylinders (Ø16-100 mm, ISO 15524 and ISO 21287) up to Profile and tie rod cylinders (Ø32-320 mm, ISO 15552 and NFE 49-001).
Innumerable design variants and sizes in the different cylinder series make it easy for the user to select the most suitable cylinder solutions for his specific application. The broad range of cylinders allows the cylinders to be specifically chosen, not only the basis of function and quality, but also under strict cost considerations.
Specifications of DNC Series Pneumatic Cylinder:
| Bore Size (mm) | 32 | 40 | 50 | 63 | 80 | 100 | 125 | ||
| Acting Type | Double Acting | ||||||||
| Fluid | Air (to be filtered by 40μm filter element) | ||||||||
| Operating Pressure Range | 0.15 to 1.0 MPa (1.5 to 10.0 bar) (22 to 145 psi) | ||||||||
| Proof Pressure | 1.5 MPa (15 bar) (215 psi) | ||||||||
| Temprature (℃) | -20 to +80 | ||||||||
| Speed Range (mm/s) | 30 to 800 | ||||||||
| Cushion Type | Variable cushion | ||||||||
| Port Size | 1/8'' | 1/4'' | 3/8'' | 1/2'' | |||||
Stroke of DNC Series Pneumatic Cylinder:
| Bore Size (mm) | Standard Stroke (mm) | Max. Std Stroke | Max. Stroke |
| 32 |
25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500 |
1000 | 1800 |
| 40 |
25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800 |
1200 | 1800 |
| 50 |
25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800, 900, 1000 |
1200 | 1800 |
| 63 | 1500 | 1800 | |
| 80 | 1500 | 1800 | |
| 100 | 1500 | 1800 | |
| 125 | 1500 | 1800 |
Ordering Code of DNC Series Pneumatic Cylinder:
