| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA25FS |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Flange Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 1''Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 1 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| Highlight: | FS Series Diaphragm Valve,CA25FS Diaphragm Valve,CA25FS Pulse Jet Valve |
||
CA25FS 1'' Inch Intergral Pilot CA25FS010-300 Pulse Jet Valve
Appliction:
The Goyen FS-series are high-performance flanged valves for reverse pulse jet systems in dust collectors. They are used around the world to frequently clean the filters in systems aiming to control the dispersion of noxious substances, improve indoor air quality in workplaces, or prevent harmful dust emissions.
These flanged valves are suitable for use in dust management systems in all types of industries and processes, including:
cement production
mining applications
silo and conveyor systems, bulk goods handling
general industrial dust collection
improving indoor workplace air quality
preventing harmful emissions
power industry: protecting boilers and gas turbines from dust particles
Technical Data of Goyen Pulse Jet Valve:
|
Model
|
CAC25FS
|
CAC45FS
|
|
Working Pressure
|
0.3~0.8Mpa
|
|
|
Working Temperature
|
-5~+55℃
|
|
|
Voltage
|
AC24V, AC110V, AC220V, DC24V
|
|
|
Inlet and Out Pipe Size
|
1 1/2'' IN, 1'' OUT
|
2'' IN, 1 1/2'' OUT
|
|
Remote or Integral
|
Integral Pilot
|
|
|
Connection Type
|
Weldless Flange
|
|
|
Body Material
|
Aluminium ADC12
|
|
|
Diaphragm Material
|
NBR(Common), Viton(Available)
|
|
Main Dimension:
CA RCA Series Pulse Jet Valve For Dust Collector System:
The dust cleaning device of the bag filter:
The dust cleaning device of the bag filter is an important component device. According to the different cleaning methods, the bag filter can be divided into the following categories. The periodic operation of the machine is used to shock the filter bag to achieve the purpose of cleaning. This method can also be divided into two types, namely continuous shock and intermittent shock. These two types of choices According to the actual situation and the density of dust to choose; the use of compressed air instead of mechanical shock, the principle is the same as the principle of mechanical shock, but the way of shock is different; when the dust is deposited, you can choose pulse cleaning, release compression The moment of air will affect the atmospheric pressure of the surrounding air.
