Focus on your demands
Offer you best solution
Sales & Support:
 |
| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA25T |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Right Angle Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 1''Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 1 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| Highlight: | Right Angle Pulse Jet Valve,CA25T Pulse Jet Valve,Goyen Type CA25T |
||
Right Angle 1'' Inch Port Thread CA25T Dust Collector Pulse Jet Valve
Goyen type T series pulse jet valves are allround series of high-performance threaded valves for reverse pulse jet systems in dust collectors. They are used around the world to frequently clean the filters in systems aiming to control the dispersion of noxious substances, improve indoor air quality in workplaces, or prevent harmful dust emissions.
These threaded valves are suitable for use in dust management systems in all types of industries and processes, including:
1. cement production
2. mining applications
3. silo and conyeyor systems
4. bulk goods handling
5. general industrial dust collection
6. improving indoor workplace air quality
7. preventing harmful emissions
Technical Data of Goyen Pulse Jet Valve:
|
Model No
|
CA15T
|
CA20T
|
CA25T
|
CA35T
|
CA45T
|
CA50T
|
CA62T
|
CA76T
|
|
Nonimal size
|
φ15
|
φ20
|
φ25
|
φ35
|
φ45
|
φ50
|
φ62
|
φ76
|
|
Port Size
|
G1/2''
|
G3/4''
|
G1''
|
G1 1/4''
|
G1 1/2''
|
G2''
|
G2 1/2''
|
G3''
|
|
Working pressure
|
0.3-0.8MPa
|
|||||||
|
Temp. range
|
-5℃ - 55℃
|
|||||||
|
Relative humidity
|
≤85%
|
|||||||
|
Working
medium
|
Compressed clean air
|
|||||||
|
Service life
|
Over 1000000 times
|
|||||||
|
Voltage
|
DC24V, AC24V, AC110V, AC220V
|
|||||||
Main Dimension:
CA RCA Series Pulse Jet Valve For Dust Collector System:
Dust Collector :
1. Centralized mechanical dust removal system
When a plant or workshop, all or a lot of exhaust points, connected into a dust removal system, this system is called a centralized mechanical dust removal system. The air duct can be divided into two types: a branch type and a collecting tube type.
2. Independent dust collector
A dust removal device in which a blower, an electric motor, a dust collector and a part of connecting pipes are all installed in a single unit is called a separate dust removing unit. The dust removing device has the characteristics of compact structure, small size and high dust removal efficiency. It can be used for dust removal of packaging machines, reciprocating feeders, crushers and screening devices. The short pipes should be arranged on the side of the dust-dissipating equipment, and the purified gas can be directly discharged indoors.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
