| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA45DD |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | Negotiation |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Dresser Nut Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 1-1/2''Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 2 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| Highlight: | CA45DD Pulse Jet Valve,Integral Pilot Pulse Jet Valve,Goyen Type CA45DD |
||
CA45DD 1-1/2'' Inch Dresser Nut Integral Pilot Pulse Jet Valve
Pulse Jet Valve play an important role in dust collector. A dust collector is a system used to enhance the quality of air released from industrial and commercial processes by collecting dust and other impurities from air or gas. Designed to handle high-volume dust loads, a dust collector system consists of a blower, dust filter, a filter-cleaning system, and a dust receptacle or dust removal system. It is distinguished from air purifiers, which use disposable filters to remove dust.
Maintenance Kits:
| Model | Nitrile | FKM | Low Temperature–60°C (–76°F) MIN. | Includes |
| CA/RCA25DD | K4502 | K4503 | K4522 | Diaphragm kits include main and secondary diaphragms and all spring |
| K4510 | K4511 | NA | 2 dresser seals, 2 dresser nuts, 2 seal retainers | |
| K0380 | K0384 | NA | o-ring, armature assembly, armature spring, ferrule |
Technical Data of Goyen Pulse Jet Valve:
|
Model
|
CA20DD
|
CA25DD
|
CA45DD
|
|
|
Nominal Size
|
20
|
25
|
45
|
|
|
Port size
|
mm
|
20
|
25
|
40
|
|
in
|
3/4
|
1
|
1 1/2
|
|
|
Number of Diaphragms
|
1
|
1
|
2
|
|
|
Flow
|
Kv
|
12
|
20
|
44
|
|
Cv
|
14
|
23
|
51
|
|
|
Pressure (Psi)
|
5 to 125
|
5 to 125
|
5 to 125
|
|
|
Temperature℃
|
NBR
|
-40 to 82
|
-40 to 82
|
-40 to 82
|
|
FKM
|
-29 to 232
|
-29 to 232
|
-29 to 232
|
|
Main Dimension:
CA RCA Series Pulse Jet Valve For Dust Collector System:
Main Part of CA45DD Pulse Valve:
Solenoid Coil
Solenoid is the generic term for a coil of wire used as an electromagnet. It also refers to any device that converts electrical energy to mechanical energy using a solenoid. The device creates a magnetic field from electric current and uses the magnetic field to create linear motion. Common applications of solenoids are to power a switch, like the starter in an automobile, or a valve, such as in a sprinkler system.
Armature
An armature assembly for a solenoid valve allows for a valve member to be retained in the closed position through a biasing force being applied therein. A moveably supported armature bolt is movable between a first position and a second position. A valve member is coupled to the armature bolt and is configured to close with the armature bolt at the second position. An armature body is coupled to the armature bolt. A resilient member adapted to hold the armature bolt at the second position so as to retain the valve member in the closed position.
Diaphragm
The purpose of a diaphragm in a diaphragm type solenoid valve is to control the air within a certain space. These control valves can also be either open or closed, depending on the movement of the magnetic core.
Main Body
1.Different body material can be used in different working environment.
2.Different Connection Type can be used in different place, suitable for different installation way.
