| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | CXSWM, CXSWL |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 work days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Cylinder Type: | Dual Rod Cylinder | Bore Size (mm): | 6, 10, 16, 20, 25, 32 |
|---|---|---|---|
| Standard Stroke (mm): | 10, 20, 30, 40, 50, 75, 100, 125, 150, 175, 200 | Max Operating Pressure: | 0.7 Mpa |
| Cushion: | Rubber Bumper On Both Ends | Port Size: | M5x0.8, 1/8'' |
| Bearing Type: | Slide Bearing, Ball Bushing Bearing | Piston Speed: | 50 To 500mm/s |
| Highlight: | Double Rod Pneumatic Cylinder,Guide Rod Pneumatic Cylinder,SMC CXSWM20-50 |
||
SMC Type CXSWM20-50 Double Guide Rod Pneumatic Cylinder
Shop for dual rod guided air cylinders. Bore sizes range from 6mm to 32mm, and stroke options range from 10mm to 200mm. These double-acting pneumatic cylinders come with a magnet that is available with PT, NPT or G thread types.
To improve load performance, guided pneumatic actuators use guide rods that are installed parallel to the piston rod which provides non-rotating, high side stability. Like rodless cylinders, dual rod air cylinders reduce uneven seal wear, and piston and rod bending.
Specifications of CXSW Series Pneumatic Cylinder:
Stroke of CXSW Series Pneumatic Cylinder:
Ordering Code of CXSW Series Pneumatic Cylinder:
Theoretical Output of CXSW Series Pneumatic Cylinder:
Brando Supply Pneumatic Air Cylinders:
| Airtac Type Pneumatic Cylinder | Festo Type Pneumatic Cylinder | SMC Type Pneumatic Cylinder |
|
|
|
