| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | EVR 6 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual Boxes, Carton, Pallet |
| Delivery Time: | 4-7 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Refrigeration Solenoid Valve | Ordering Number: | 032F8072, 032L8072 |
|---|---|---|---|
| Port Size: | 3/8'' (10mm) | Connection Type: | Flare (SAE) |
| Function: | 2 Way, Normally Closed | Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 120VAC, 220VAC, 230VAC |
| Body Material: | Brass | Seal Material: | PTFE |
| System Line Application: | Discharge Line, Hot Gas Defrost Line, Liquid Line, Suction Line | Application: | Chiller, Freezer, Air Conditioning, Cooler, Etc |
| Highlight: | 032L8072 Refrigeration Solenoid Valve,Flare Refrigeration Solenoid Valve,Danfoss Type 032L8072 |
||
3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072
The shown is danfoss type EVR 6 solenoid valve, 3/8'' (10mm) SAE flare port size, 2 way normally closed, 12V DC, 24V DC, 24V AC, 110V AC, 220V AC voltages (other voltages can be customized), ordering code: 032F1212, 032L1212.
A solenoid valve is an electronically operated device. The valve is commonly used to replace a manual valve or where remote control is desirable. A solenoid is operated by opening and closing an orifice in a valve body that permits or prevents flow through the valve. The orifice is opened or closed through the use of a plunger that is raised or lowered within a sleeve tube by energizing the coil. The bottom of the plunger contains a compatible sealing material, which closes off the orifice in the body, stopping flow through the valve.
Main Dimension of EVR Series Solenoid Valve:
|
Model
|
Port Size
|
H1
|
H2
|
L
|
L2
|
||
|
SAE (Flare)
|
ODF (Solder)
|
Inch
|
mm
|
mm
|
mm
|
mm
|
mm
|
|
EVR 3
|
EVR 3
|
1/4''
|
6
|
14
|
71
|
102
|
7
|
|
EVR 3
|
EVR 3
|
3/8''
|
10
|
14
|
73
|
117
|
10
|
|
EVR 6
|
EVR 6
|
3/8''
|
10
|
14
|
79
|
111
|
10
|
|
EVR 6
|
EVR 6
|
1/2''
|
12.8
|
14
|
79
|
127
|
10
|
|
EVR 10
|
EVR 10
|
1/2''
|
12.8
|
16
|
79
|
127
|
10
|
|
EVR 10
|
EVR 10
|
5/8''
|
16
|
16
|
79
|
160
|
12
|
|
|
EVR 15
|
5/8''
|
16
|
19
|
86
|
176
|
12
|
|
|
EVR15
|
7/8''
|
22
|
19
|
86
|
176
|
17
|
|
|
EVR 20
|
7/8''
|
22
|
20
|
90
|
191
|
17
|
|
|
EVR 20
|
1 1/8''
|
28.8
|
20
|
90
|
214
|
22
|
|
|
EVR 22
|
1 3/8''
|
35
|
20
|
90
|
281
|
25
|
|
|
EVR 25
|
1 1/8''
|
28.8
|
38
|
138
|
256
|
22
|
|
|
EVR25
|
1 3/8''
|
35
|
38
|
138
|
281
|
25
|
|
|
EVR 32
|
1 3/8''
|
35
|
47
|
111
|
281
|
25
|
|
|
EVR 32
|
1 5/8''
|
42
|
47
|
111
|
281
|
29
|
|
|
EVR 40
|
1 5/8''
|
42
|
47
|
111
|
281
|
29
|
|
|
EVR 40
|
2 1/8''
|
54
|
47
|
111
|
281
|
34
|
Product Video of EVR 6 3/8'' Danfoss Type Solenoid Valve:
Ordering Code of EVR Solder Connections, Normally Closed (NC) - Separate Valve Bodies:
Ordering Code of EVR Flare Connections, Normally Closed (NC) - Separate Valve Bodies:
EVR Solenoid Valve Parts For you to choose:
Solenoid Valve Armature Assembly Solenoid Valve Coil
More Refrigeration Valve For you to choose:
Danfoss Type Solenoid Valve Ammonia Solenoid Valve Castel Type Solenoid Valve
Expansion Valve Refrigerator Solenoid Valve
