| Place of Origin: | CHINA |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | AFC, BFC |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | bubble bag, inner box, carton, then pallet |
| Delivery Time: | 7 working days after payment |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Product Name: | Filter Regulator Lubricator | Model: | AFC1500, AFC2000, BFC2000, BFC3000, BFC4000 |
|---|---|---|---|
| Fluid: | Air | Port Size: | 1/8'', 1/4'', 3/8'', 1/2'' |
| Filtering Grade: | 40 μm Or 5 μm | Max Pressure: | 1.0Mpa (145Psi) |
| Proof Pressure: | 1.5Mpa (215Psi) | Capacity Of Drain Bowl: | 15CC, 60CC |
| Capacity Of Oil Bowl: | 25CC, 90CC | Recommended Lubricant: | ISO VG 32 Or Equivalent |
| Highlight: | Filter Regulator Lubricator 1/4'',Air Line Filter Regulator & Lubricator,Airtac AFC2000 |
||
AFC2000 Airtac Type 1/4'' Air Line Filter Regulator & Lubricator
Product Featres of AFC, BFC series Filter Regulator Lubricator:
1.The structure is delicate and compact, which is convenient for installation and application.
2.The pressed-in self-locking mechanism can prevent the abnormal movement of the set pressure caused by external interfere.
3.The pressure loss is low and the efficiency of water separating is high.
4.The quantity of oil dripping can be directly observed through transparent check-dome.
5.In addition to standard type, lower pressure type is optional (The highest adjustable pressure is 0.4MPa).
Specification of AFC, BFC series Filter Regulator Lubricator:
| Model | AFC1500 | AFC2000 | BFC2000 | BFC3000 | BFC4000 | |
| Fluid | Air | |||||
| Port Size | 1/8'' | 1/4'' | 1/4'' | 3/8'' | 1/2'' | |
| Filtering Grade | 40μm or 5μm | |||||
| Pressure Range |
Semi-auto and automatic drain: 0.15 to 0.9 MPa (20 to 130 psi) Manual drain: 0.5 to 0.9 MPa (7 to 130 psi) |
|||||
| Max Pressure | 1.0 MPa (145 psi) | |||||
| Proof Pressure | 1.5 MPa (215 psi) | |||||
| Temperature Range | -5 to 70℃ (unfreeze) | |||||
| Capacity of drain bowl | 15CC | 60CC | ||||
| Capacity of oil bowl | 25CC | 90CC | ||||
| Recommand lubricant | ISO VG 32 or equivalent | |||||
| Constitute | Filter-Regulator | AFR1500 | AFR2000 | BFR2000 | BFR3000 | BFR4000 |
| Lubricator | AL1500 | AL2000 | BL2000 | BL3000 | BL4000 | |
Ordering Code of AFC, BFC series Filter Regulator Lubricator:
Inner Structure of AFC, BFC series Filter Regulator Lubricator:
Dimension of AFC, BFC series Filter Regulator Lubricator:
