| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4H330C-10 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Fluid: | Air (to Be Filtered By 40μm Filter Element) | Operation: | Manual Control Direct Acting Type |
|---|---|---|---|
| Port Size: | In=Out=3/8'', Exhaust=1/4'' | Valve Type: | 5 Way 3 Position |
| Pressure Range: | 0 To 1.0 MPa | Max Pressure Resistance: | 1.5 MPa |
| Temperature Range: | -20 To +70℃ | Body Material: | Aluminum Alloy |
| Highlight: | Hand Lever Pneumatic Valve,Hand Lever Valve 5 Way,Airtac 4H330C-10 |
||
4H330C-10 Airtac Type Hand Lever Pneumatic Valve 5 Way 3 Position
Characteristics:
1. Made of high quality material, high toughness and corrosion resistance.
2. Pneumatic control valve is the pneumatic system to control air pressure and direction, and ensure the normal work of pneumatic actuator components or institutions of all kinds of pneumatic components.
3. The compaction of the structure and the gasket material guarantees a great connection tightness.
4. Compact size and light weight, good sealing performance.
5. Used in industrial control systems to adjust direction, speed and other parameters of the environment.
Technical Data of 4H series Hand Lever Valve:
| Model | 210-06 | 230-06 | 210-08 | 230-08 | 310-08 | 330-08 | 310-10 | 330-10 |
| Fluid | Air (to be filtered by 40μm filter element) | |||||||
| Operating | Manual control direct acting type | |||||||
| Port Size |
In=Out= Exhaust=1/8'' |
In=Out=1/4'', Exhaust=1/8'' |
In=Out= Exhaust=1/4'' |
In=Out=3/8'', Exhaust=1/4'' |
||||
| Orifice Size (Cv) |
4H210-08: 17.0 mm² (Cv=1.0) 4HA230C-08: 13.6 mm² (Cv=0.8) |
4H310-08: 28.0 mm² (Cv=1.65) 4HA330C-08: 21.3 mm² (Cv=1.25) |
||||||
| Valve Type | 5/2 way | 5/3 way | 5/2 way | 5/3 way | 5/2 way | 5/3 way | 5/2 way | 5/3 way |
| Pressure Range | 0 to 1.0 MPa (0 to 145 psi) | |||||||
| Proof Pressure | 1.5 MPa (215 psi) | |||||||
| Temperature | -20 to +70℃ | |||||||
| Body Material | Aluminum Alloy | |||||||
| Operating Angle | ±15° | ±8.5° | ±15° | ±8.5° | ±18° | ±10° | ±18° | ±10° |
Ordering Code of 4H series Hand Lever Valve:
Dimension of 4H series Hand Lever Valve:
Inner Structure of 4H series Hand Lever Valve:
Production Video of BRANDO Pneumatic Valves:
