CA15T 1/2'' Inch Dust Collector Baghouse System Pulse Jet Valve

CA15T 1/2'' Inch Dust Collector Baghouse System Pulse Jet Valve

CA15T Goyen Type Right Angle Solenoid Air Controlled Pulse Valve For Dust Bag Filter. High performance diaphragm valve with threaded ports. Available with integral pilot or as remotely piloted valve. Outlet at 90 degrees to inlet.

The 'T' series pulse jet valve are available in 3/4", 1", 1.5",2", 2.5", 3" port sizes.

The pulse blowing performance of the electromagnetic pulse valve is more powerful. The valve interface has three types of internal thread connection, double plug connection and flange inlet / sliding outlet connection, which makes the maintenance of the pulse valve easier and faster.

Please thoroughly purge the air bag and pipeline before installation (the electromagnetic pulse valve is in the closed state, after entering the body into the air bag, open the drain valve, and let the impurities discharge with the gas. Then repeat it a few times.) Then open the solenoid pulse valve to avoid foreign body damage to the diaphragm causing solenoid pulse valve failure.
Three, when the solenoid pulse valve failure, in order to timely isolation and easy maintenance, it is recommended to install bypass (bypass) device.
Four. The arrow on the body of the solenoid pulse valve should be consistent with the flow direction of the medium. Otherwise, normal use cannot be guaranteed.
Five, solenoid pulse valve valve is the best way to install perpendicular to the horizontal pipeline, the coil upward. When conditions do not permit, tilt ±30° is allowed.
In order to ensure the normal use of the electromagnetic pulse valve, please install an oil-water separator in front of the electromagnetic pulse valve.

Specification:

Technical Dimension :

Deconstruction

Goyen Type 'T' Series Pulse Jet Valve:

Note:

1) AC and DC solenoid valves are selected according to the type of power supply.

2) For use in corrosive or explosive environments, it is preferred to choose corrosion resistance according to safety requirements.

3) If the environmental space is limited, please use a multi-function solenoid valve, because it bypasses the bypass and three manual valves and is convenient for online maintenance.

4) AC220V and DC24V are preferred for voltage specifications.

5) Waterproof solenoid valve should be selected in the environment with high relative humidity and water drops and rain.

6) The rated current and power consumption should be selected according to the power supply capacity. It should be noted that the VA value is higher at the time of AC starting, and the indirect pilot solenoid valve should be preferentially selected when the capacity is insufficient.

We also sell a variety of products such as Goyen type CA/RCA series dust collector valves, ASCO type SCG series pulse jet valve, SBFEC type DMF series diaphragm valve, and so on. And we also supply their repair kits (solenoid coil, armature assembly, o-ring, spring, diaphragm).

Welcome to your any question and inquiry!
