| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 2W400-40K |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 10 to 15 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 50000pcs per month |
| Product Name: | Solenoid Valve | Port Size: | 1-1/2'' |
|---|---|---|---|
| Orifice Size: | 40mm | Working Media: | Water, Air, Gas, Liquid, Etc |
| Body Material: | Brass | Diaphragm Material: | NBR, EPDM, FKM |
| Temperature Range: | NBR: -5 To +80℃, EPDM: -5 To +120℃, FKM: -10 To +150℃ | Pressure Range: | 0 To 0.8 MPa |
| Operation: | Direct Lifting Diaphragm | Function: | 2 Way, Normally Open |
| Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | ||
| Highlight: | Normally Open Brass Solenoid Valve 1.5'',Normally Open Water Solenoid Valve 1.5'',Normally Open Brass Solenoid Valve DC24V |
||
1.5'' 2-Way Normally Open Brass Water Solenoid Valve AC220V AC110V DC24V DC12V
2W-K series are 2 way normally open solenoid valves with port sizes from 3/8'' to 2''. The standard valve body material is brass, and the standard diaphragm material is NBR, EPDM or FKM can be customized according to your requirements to control different media like water, air, gas and liquids, etc. The working pressure range is from 0 to 8 bar, and there are various voltages for you to choose, 12VDC, 24VDC, 24VAC, 110VAC or 220VAC. If you have demands, pls contact us!
Technical Data:
|
Model No
|
2W160-10K
|
2W160-15K
|
2W200-20K
|
2W250-25K
|
2W350-35K
|
2W400-40K
|
2W500-50K
|
|
Orifice Size
|
16mm
|
16mm
|
20mm
|
25mm
|
35mm
|
40mm
|
50mm
|
|
Port Size
|
3/8''
|
1/2''
|
3/4''
|
1''
|
1-1/4''
|
1-1/2''
|
2''
|
|
Body Material
|
Brass
|
||||||
|
Diaprhagm Material
|
NBR, EPDM, FKM
|
||||||
|
Working Medium
|
Water, Air, Gas, Liquid, etc
|
||||||
|
Operation
|
Direct Lifting Diaphragm
|
||||||
|
Function
|
2 Way Normally Open
|
||||||
|
Fluid Viscosity
|
20 CST below
|
||||||
|
Working Pressure
|
0 to 8 bar
|
||||||
|
Working Temperature
|
NBR: -5 to +80℃
EPDM: -5 to +120℃ FKM: -10 to +150℃ |
||||||
|
Voltage
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
|
||||||
Main Dimension:
|
Model No
|
Port
|
A
|
B
|
C
|
D
|
|
2W160-10K
|
3/8''
|
63
|
56
|
181
|
118
|
|
2W160-15K
|
1/2''
|
63
|
56
|
181
|
118
|
|
2W200-20K
|
3/4''
|
66
|
56
|
122
|
123
|
|
2W250-25K
|
1''
|
90
|
76
|
130
|
147
|
|
2W350-35K
|
1-1/4''
|
99
|
76
|
134
|
160
|
|
2W400-40K
|
1-1/2''
|
115
|
93
|
160
|
165
|
|
2W500-50K
|
2''
|
133
|
93
|
170
|
176
|
Our Production:
Similar Products:
|
|
|
|
|
Normally Open 3/8'' to 2'', 8 bar max |
Normally Open 1/8'' to 3/8'', 30 bar max |
Normally Open
1/4'' to 1'', 16 bar max |
Normally Open 1-1/4'' to 2'', 16 bar max |
