| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | PU220A-03 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, Western Union,Paypal, MoneyGram |
| Supply Ability: | 300000 sets per month |
| Port Size: | 3/8'' | Orifice Size: | 13mm |
|---|---|---|---|
| Function: | 2 Way, Normally Closed | Operation: | Assisted Lift |
| Body Material: | Brass | Seal Material: | NBR |
| Voltages: | 24VDC, 110VAC, 220VAC | Working Pressure Range: | 0 To 7 Kg/cm² |
| Highlight: | Brass Solenoid Valve 24VDC,Shako Solenoid Valve PU220,Shako PU220A-03 |
||
PU220A-03 Shako Type 2 Way NC Brass Solenoid Valve 3/8'' 24VDC
PU220A series Solenoid Vave Features:
1. Port 3/8, 1/2, 3/4 or 1" BSP or NPT thread
2. PU220A 2/2 way normally closed, PU220AN normally open.
3. Zero rated / direct acting 0 to 8.5 bar, special option high power 18.5 Watt coil for 0~12 bar
4. Sealing NBR, EPDM, Viton or HNBR.
5. Flange type is available for JIS 10K, ANSI 150LB and PN16.
6. Quick response.
7. Stainless steel extruded stem provides exceptional durability.
8. IP65 100% ED coil with option for Ex-proof coil.
9. Most voltages available.
Main Dimension of PU220A series Solenoid Valve:
Technical Data of PU220A series Solenoid Valve:
Ordering Code of PU220A series Solenoid Valve:
Brando Solenoid Valve Factory Production Video:
More Shako Type Solenoid Valves for you to choose:
|
|
| PU220A Series | PU225A Series |
|
|
| SPU225A Series | PU225S Series |
