| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | PU225A-06 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, Western Union,Paypal, MoneyGram |
| Supply Ability: | 300000 sets per month |
| Port Size: | 3/4'' | Orifice Size: | 25mm |
|---|---|---|---|
| Function: | 2 Way, Normally Closed | Operation: | Diaphragm Pilot Operated |
| Body Material: | Brass | Seal Material: | NBR |
| Voltages: | 24VDC, 110VAC, 220VAC | Working Pressure Range: | 0.05 To 1 MPa |
| Highlight: | Brass Solenoid Valve 3/4 Inch,Shako Solenoid Valve PU225A,Shako PU225A-06 |
||
PU225A-06 Shako Type 3/4'' Brass Solenoid Valve 24 110 220 Volt
Shako type PU225A series solenoid valve features:
1. Port thread 3/8, 1/2, 3/4, 1, 11/4, 11/2, 2" BSP/NPT or Flange (F) JIS10K, (F3) ANSI150Lb, (F4) PN16.
2. Sealing NBR, EPDM or Viton.
3. 0.5 to 10 bar differential, 15 bar maximum working.
4. PU225A 2/2 normally closed, PU225AN 2/2 normally open.
5. Pilot acting for low starting pressure
6. Large flow rate and high working pressure.
7. Quick response.
8. Stainless steel stem provides exceptional durability.
9. Most voltages available from 12v, 24volt, 48volt, 110volt, 230volt and 380 volt AC or DC, optional ATEX coil.
10. Suitable media NBR - air, water, neutral gases and mineral oils - Viton fuel oil, gasoline, hi-test gasoline and diesel fuels - EPDM hot water and liquid detergents.
Main Dimension of PU225A series Solenoid Valve:
Technical Data of PU225A series Solenoid Valve:
Ordering Code of PU225A series Solenoid Valve:
Brando Solenoid Valve Factory Production Video:
More Shako Type Solenoid Valves for you to choose:
|
|
| PU220A Series | PU225A Series |
|
|
| SPU225A Series | PU225S Series |
