| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | VX32 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1/8'', 1/4'' | Orifice Size: | 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm |
|---|---|---|---|
| Operation Mode: | 3 Way, Normally Open | Action: | Direct Acting |
| Body Material: | Brass, Stainless Steel | Seal Material: | NBR, EPDM, FKM |
| Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | Pressure Range: | 0 To 1 MPa |
| Highlight: | 3 Way Normally Open Brass Solenoid Valve,Three Way Solenoid Valve,3/2 Way Solenoid Valve |
||
VX32 SMC Type 3 Way Normally Open Brass Solenoid Valve 1/8'' 1/4''
The multi-purpose 3/2 way direct acting solenoid valves are mainly suitable in the neutral gaseous and liquid fluid pipeline automatically control. It is suitable the medium of gas, water, oil, vacuum, steam. Can be operated with zero pressure difference & circulation direction is random.
Main Dimension of VX Series Solenoid Valve:
Technical Data of VX Series Solenoid Valve:
|
Model
|
Function
|
Orifice Size
(mm)
|
Port Size
(inch)
|
CV
|
Working Pressure (bar)
|
Medium Temperature
|
|
|
AC
|
DC
|
||||||
|
VX31
|
3 Way, Normally Closed
|
1.5
|
1/8'', 1/4''
|
0.07
|
13
|
11
|
NBR: -5 to +85℃,
EPDM: -5 to +150℃,
FKM: -10 to +150℃
|
|
2.0
|
0.14
|
11
|
9
|
||||
|
2.5
|
0.21
|
9
|
7
|
||||
|
3.0
|
0.25
|
6
|
4
|
||||
|
4.0
|
0.35
|
3.5
|
2
|
||||
|
VX32
|
3 Way, Normally Open
|
1.5
|
0.07
|
13
|
11
|
||
|
2.0
|
0.14
|
11
|
9
|
||||
|
2.5
|
0.21
|
9
|
7
|
||||
|
3.0
|
0.25
|
6
|
4
|
||||
|
4.0
|
0.35
|
3.5
|
2
|
||||
|
VX33
|
3 Way, Universal Operation
|
1.5
|
0.07
|
13
|
11
|
||
|
2.0
|
0.14
|
11
|
9
|
||||
|
2.5
|
0.21
|
9
|
7
|
||||
|
3.0
|
0.25
|
6
|
4
|
||||
|
4.0
|
0.35
|
3.5
|
2
|
||||
Working flow direction of VX Series Solenoid Valve:
