| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | AE25 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic Bags, Cartons, Pallet |
| Delivery Time: | 4-7 Days |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Product Name: | Diaphragm Repair Kit | Suitable Valves: | AE1825B, AE2825R |
|---|---|---|---|
| Suitable Valve Port Size: | 1'' | Diaphragm Material: | TPE |
| Diaphragm Outer Diameter: | φ77.0mm | Seat OD: | φ45.5mm |
| Seat ID: | φ16.0mm | Bleed Hole: | 1 |
| Spring: | Without | Packaging: | Individual Plastic Bag Sealed |
| Highlight: | 1 Inch NBR Diaphragm,Pulse Jet Valve NBR Diaphragm,Autel Type Membrane |
||
1 Inch Autel Type Dust Collector Pulse Jet Valve NBR Diaphragm
The TPE diaphragm kit is the heart of the AUTEL 1'' AE1825B, AE2825R pulse valve, the material advantage are high temperature resistance, fatigue resistance, high strength, high resilience. The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life, even under harsh conditions. The characteristics of AUTEL pulse valve compare favourably with other products on the market are the result of an innovative housing design based on advanced air technology and the application of TPE diaphragm technology. The TPE diaphragm is the key component in diaphragm pulse jet valves designed to provide short pressure decay times and high kv-values. Service life is 4-5 times longer than that of comparable, conven-tional fabric diaphragms.
YouTube video of TPE Diaphragm Repair Kit For AUTEL Pulse Valve:
Main dimension of Diaphragm Repair Kit For 1'' AUTEL Pulse Valve:
Details of Diaphragm For AUTEL 1'' AE1825B AE2825R Pulse Valve:
Available Models of Diaphragm Valve Repair Kits For AUTEL Pulse Valves:
Factory Production Pictures of Solenoid Valve Diaphragm Kits:
Diaphragm Features:
1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.
2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.
3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.
4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility
5. EPDM, Viton all available.
