RCAC20T4002 RCAC20ST4002 3/4'' Pulse Valve K2034 Shockwave Diaphragm

RCAC20T4002 RCAC20ST4002 3/4'' Pulse Valve K2034 Shockwave Diaphragm

The shown is K2034 shockwave diaphragm repair kit for repair and replace Goyen RCAC20T4, RCAC20ST4, RCAC20DD4, RCAC20FS4 remote pilot pulse valve diaphragm. Because the diaphragm of pulse valve is a flexible mechanism which needs to open and close frequently to control the air flow, it requires good flexibility and as high sealing as possible. This diaphragm is made of TPE, which has many advantages, like Good chemical resistance, Aging resistance, Can be used in a wide temperature range from -40 ℃ to 85 ℃, Service life is 4-5 times longer than that of comparable, conven-tional fabric diaphragms.

1. Product Name: K2034 Shockwave Kit RCAC20T4,ST4,DD4,FS4
2. Diaphragm Material: TPE
3. Diaphragm Outer Distance: 72mm
4. Center Distance: 76mm
5. Mounting Hole Size: 8.5mm
6. Seat OD: 34mm
7. Seat ID: 16mm
8. Spring: Without
9. Air Hole: With
10. Packaging: Individual Sealed


YouTube video of K2034 Shockwave Kit RCAC20T4, ST4, DD4, FS4:

Main dimension of K2034 Goyen Type Shockwave Diaphragm Repair Kit:

Details display of K2034 Goyen Type RCAC20 Diaphragm Valve Repair Kit:


Available Models of Goyen Type 3/4'' RCA/RCAC Diaphragm Valve Repair Kits:

Factory Production Pictures of Solenoid Valve Diaphragm Kits:

Brief introduction of K2034 Shockwave Kit:

1. K2034 pulse valve repair kit mounted on RCAC20T4, RCAC20ST4, RCAC20DD4 & RCAC20FS4 diaphragm valves is a shockwave springless diaphragm. The pulse valves with shockwave diaphragm are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation.

2. Proprietary highperformance engineering thermoplastic Elastomer (TPE).

3. The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life.

4. Working Principle: When different pressure (or force) acts on both sides of the diaphragm of the pulse valve, the diaphragm moves to the lower side of the pressure, resulting in the displacement of the center of the diaphragm.

Delivery:
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.
