CNOMO Size 30 3/2 Way Brass Plunger Iron Core Solenoid Valve Stem

CNOMO Size 30 3/2 Way Brass Plunger Iron Core Solenoid Valve Stem

There are four basic types of 3-way solenoid valves. Each of these different types is used for different purposes. Two of the main types include 3-way normally closed and 3-way normally open. These two valves vary simply by the fact that one has a normally open passageway, while the other has a normally closed one. If the 3-way valve is needed for more complex functions, either the 3-way directional control or the 3-way multipurpose valve can be used.

Static core and movable plunger are made of materials which has high magnetic permeability, low magnetic residual and excellent anti-corrosion and rust resistance,All of the features make the products durable and responsive

By applying 0.5mm, H62 copper seamless tube,products have excellent features of durability, anti-corrosion as well as rust resistance

Hydraulic rolling technology makes seal condition much safer than normal clamp process.

Imported stainless steel spring wires makes stable force and good resilience.

Seal material is made of excellent NBR,temperature rangs from -30°-100°.

Dimension of BAPC310033814 Armature Assembly:

Technical Data:

Product Features:

1. Fixed core and movable core (plunger):
Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.

2. Guide tube (plunger tube):
Options of brass and stainless steel, grade of H62 or SUS304;
Wall thickness from range of 0.25~2.5mm, others could be customized;
Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering. Machining from entire solid bar directly is also available.

3. Spring:
Rustproof SUS304 stainless steel, with good performance of restore.

4. Seals:
Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.

5 Shading ring:
Cooper and silver material available.

6. Washer and retaining nut provided if has demands.

More Solenoid Valve Armature Assembly for you to choose:

*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

*According to tube material: Brass, Stainless Steel

*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
