| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | DB16 |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000 sets per month |
| Product Name: | Pulse Valve Diaphragm | Diaphragm Material: | NBR, VITON |
|---|---|---|---|
| 1 Set: | 1pc DB16 Diaphragm, 1pc Spring | Fitted Pulse Valve Model: | VNP206, VEM206, VNP306, VEM306 |
| Highlight: | DB16 Diaphragm Repair Kit,DB16/G Diaphragm Repair Kit,Mecair Membrane Kit |
||
DB16 DB16/G 3/4'' Diaphragm Repair Kit For Mecair Pulse Jet Valve
DB16 ( DB16/G ) Diaphragm ( Membrane ) for Mecair pulse valve VNP206, VEM206, VNP306, VEM306; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse valves are operated by integral solenoid pilot operator. When the valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pilot operated valve is de - energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the valve.
Diaphragm valves come in a range of configurations to suit all types of pulse jet dust collector cleaning designs. Diaphragm valves use a flexible molded diaphragm to regulate airflow through the filters for optimal cleaning. The diaphragm valve creates a pulse of air that shakes through the bag, shaking off any dirt on the outside of the bag and cleaning the filter.
Ordering Code of Diaphragm For Mecair Pulse Valve:
|
Ordering code
|
Fitted valve code
|
Valve port size
|
Material
|
|
DB16/G
|
VNP206, VEM206, VNP306, VEM306
|
3/4''
|
NBR
|
|
DB18/G
|
VNP208, VEM208, VNP308, VEM308,
VNP408, VEM408
|
1''
|
NBR
|
|
DB18M
|
VNP608, VEM608, VNP708, VEM708
|
1'', 1-1/2''
|
NBR
|
|
DB112/G
|
VNP212, VEM212, VNP312, VEM312,
VNP412, VEM412
|
1-1/2''
|
NBR
|
|
DB114/C
|
VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714 |
1-1/2''
|
NBR
|
|
DB116/C
|
VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716 |
2''
|
NBR
|
|
DB120/C
|
VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM720 |
2-1/2'', 3''
|
NBR
|
|
Tips: EPDM, FKM all available.
|
|||
Dimension of DB16 Diaphragm:
Video of DB16 Diaphragm:
Pictures of Pulse Valve Membrane Production:
