| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | M40 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic Bags, Cartons, Pallet |
| Delivery Time: | 4-7 Days |
| Payment Terms: | L/C, T/T, Western Union, Paypal, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Product Name: | M40 Diaphragm Repair Kit | Suitable Valves: | 1 1/2'' FP40, FM40, DP40, DM40, EP40, EM40 |
|---|---|---|---|
| Diaphragm Material: | NBR (Buna) | Mounting Hole Size: | φ8.5mm |
| Diaphragm Outer Diameter: | φ122mm | Center Distance: | φ122mm |
| Bleed Hole: | 1 | Spring: | 2 |
| Packaging: | Individual Plastic Bag Sealed | ||
| Highlight: | Turbo Diaphragm Kit,M40 Diaphragm Kit,m40 turbo kit |
||
Turbo Diaphragm Kit M40 Nitrile For Pulse Jet Valve FP40 DP40
1½" Turbo Diaphragm Repair Kit consisting of a double diaphragm (M45+M10) plus springs (TM0L40 + TMOL11G)
M40 & M40V Diaphragm Repair Kit is suitablr to the 1 1/2'' FM45, FP45, DM45 & DP45 Turbo Valves. There are two kinds of materials for this diaphragm, one is Nitrile and the other is Viton, Nitrile is generally used, Viton is resistant to high temperature and the price is slightly higher.
The M40 Kit is the Nitrile Kit, for use with standard temperature applications
The M40V Kit is the Viton Kit, for use with high temperature applications
YouTube video of M40 Diaphragm Repair Kit For 1.5'' Turbo Pulse Valve:
Main dimension of FP40, FM40, DP40, DM40, EP40, EM40 Valve Diaphragm:
Details display of M40 Repair Kit Diaphragm For 1 1/2'' Turbo Pulse Valve:
Available Models of Diaphragm Valve Repair Kits For Turbo Pulse Valves:
Tips: The related solenoid coils and armature assembly are all supplied.
Factory Production Pictures of Solenoid Valve Diaphragm Kits:
By registering for a customized catalog, Brando offers a fast and easy way to order your replacements parts. We'll take your system specifications and create a catalog based on your system making it a breeze to find the right products for your installation.
We offer competitive accessories and replacement parts for dust collectors as following:
1. Pulse Controller
2. Diaphragm Valves
3. Repair Kits (Solenoid Coil, Armature Assembly, Diaphragms)
Working Principle: When different pressure (or force) acts on both sides of the diaphragm of the pulse valve, the diaphragm moves to the lower side of the pressure, resulting in the displacement of the center of the diaphragm.
Applications: The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation.
