| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4V410-15 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Type: | 5/2 Way, Single Solenoid | Port Size: | In=Out=Exhaust=1/2'' |
|---|---|---|---|
| Pressure Range: | 0.15 To 0.8MPa (21 To 114PSI) | Max Pressure Resistance: | 1.5MPa (215PSI) |
| Body Material: | Aluminum Alloy | Max. Frequency: | 3 Cycle / Second |
| Highlight: | 4V410-15 Solenoid Air Valve,Pneumatic Solenoid Air Valve,4v410-15 ac220v |
||
4V410-15 Pneumatic Solenoid Air Valve Internally Piloted Acting
Most 5/2-way valves have a movable spool with seals along the length in a cylinder. The valve ports connect to this central cylinder. By moving the spool through the cylinder, the valve ports are connected or blocked. Furthermore, the valve can be direct operated or pilot operated. With direct operation, the actuator is directly connected to the spool. With pilot operation, the valve uses the inlet pressure to help move the spool. The valve contains a small internal pneumatic cylinder that actuates the spool. The filling and emptying of this cylinder is controlled by the actuator, for example a solenoid. 5/2-way valves are usually pilot operated.
BRNADO pneumatic valves offer reliability, low power consumption, and have a long life. They are have prewired connections that makes installation, maintenance, and control simple.
Technical Data of 4V400 Series Pneumatic Solenoid Valves:
|
Model
|
4v410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
|
Fluid
|
Air (to be filtered by 40 μ m filter element)
|
||||
|
Acting
|
Internal Pilot or External Pilot
|
||||
|
Port Size
|
In=Out=Exhaust=1/2''
|
||||
|
Orifice Size
|
50.00 mm² (Cv=2.79)
|
30.00 mm² (Cv=1.68)
|
|||
|
Valve Type
|
5 Way 2 Position
|
5 Way 3 Position
|
|||
|
Operating Pressure
|
0.15~0.8 MPa (21~114 psi)
|
||||
|
Proof
|
1.5 MPa (215 psi)
|
||||
|
Temperature ℃
|
-20 to 70
|
||||
|
Material of Body
|
Aluminum Alloy
|
||||
|
Max. Frequency
|
3cycle/sec
|
||||
Dimension of 4V410-15 Pneumatic Solenoid Valve:
Product video of 4V410-15 Pneumatic Solenoid Valve:
Production Video of Pneumatic Solenoid Valve:
More Pneumatic Products for you to choose:
