| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | GBC 35s |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 200000 pcs per month |
| Product Name: | Refrigeration Shut-off Ball Valve | Ordering Code: | 009L7528 |
|---|---|---|---|
| Port Size (Inch): | 1 3/8'' | Port Size (mm): | 35mm |
| Access Port: | Without | Max Working Pressure: | 45 Bar / 650 Psig |
| Medium Temperature Range: | -40 °C To 100 °C / -40 °F To 212 °F | Refrigerant: | CFC, HCFC, HFC |
| Highlight: | Brass Refrigeration Ball Valve,Refrigeration Ball Valve Danfoss,Danfoss Gbc Ball Valve 35s |
||
GBC 35s 1 3/8'' Danfoss Type Brass Refrigeration Ball Valve 009L7528
Refrigeration ball valves, type GBC, are manually operated shut-off valves suitable for bi-directional flow. The GBC valves are used in liquid, suction and hot gas lines in refrigeration systems of food retail industry.
The design, the welding and the sealing material vouch for a safe construction suited for even the most demanding requirements, for instance high working pressure when operated with R410A.
Video of GBC 35s Refrigeration Shut-off Ball Valve:
Technical Data of GBC series Refrigeration Ball Valves:
Dimension of GBC series Refrigeration Ball Valves:
| Model No | Port Size | H | H1 | L | L1 | L2 | L3 | L4 | L5 | M | D | d |
| GBC 6s | 1/4'' | 50 | 15 | 139 | 7 | 75 | 73 | 22 | 31 | M4x0.7 | 14 | 1.5 |
| 6mm | 50 | 15 | 139 | 7 | 75 | 73 | 22 | 31 | M4x0.7 | 14 | 1.5 | |
| GBC 10s | 3/8'' | 50 | 15 | 139 | 8 | 75 | 73 | 22 | 31 | M4x0.7 | 14 | 1.5 |
| 10mm | 50 | 15 | 139 | 8 | 75 | 73 | 22 | 31 | M4x0.7 | 14 | 1.5 | |
| GBC 12s | 1/2'' | 50 | 15 | 161 | 10 | 75 | 84 | 22 | 31 | M4x0.7 | 14 | 1.5 |
| 12mm | 50 | 15 | 161 | 10 | 75 | 84 | 22 | 31 | M4x0.7 | 14 | 1.5 | |
| GBC 16s | 5/8'' | 50 | 15 | 161 | 12 | 86 | 84 | 22 | 31 | M4x0.7 | 14 | 1.5 |
| 16mm | 50 | 15 | 161 | 12 | 86 | 84 | 22 | 31 | M4x0.7 | 14 | 1.5 | |
| GBC 18s | 3/4'' | 58 | 19 | 185 | 14 | 99 | 96 | 30 | 37 | M4x0.7 | 19 | 1.5 |
| 18mm | 58 | 19 | 185 | 14 | 99 | 96 | 30 | 37 | M4x0.7 | 19 | 1.5 | |
| GBC 22s | 7/8'' | 58 | 19 | 185 | 17 | 99 | 96 | 30 | 37 | M4x0.7 | 19 | 1.5 |
| 22mm | 58 | 19 | 185 | 17 | 99 | 96 | 30 | 37 | M4x0.7 | 19 | 1.5 | |
| GBC 28s | 1 1/8'' | 80 | 25 | 208 | 20 | 112 | 108 | 38 | 44 | M4x0.7 | 26 | 1.5 |
| 28mm | 80 | 25 | 208 | 20 | 112 | 108 | 38 | 44 | M4x0.7 | 26 | 1.5 | |
| GBC 35s | 1 3/8'' | 89 | 30 | 251 | 25 | 136 | 130 | 48 | 44 | M6x1.0 | 32 | 1.5 |
| 35mm | 89 | 30 | 251 | 25 | 136 | 130 | 48 | 44 | M6x1.0 | 32 | 1.5 | |
| GBC 42s | 1 5/8'' | 110 | 35 | 281 | 29 | 151 | 145 | 55 | 56 | M6x1.0 | 38 | 1.5 |
| 42mm | 110 | 35 | 281 | 29 | 151 | 145 | 55 | 56 | M6x1.0 | 38 | 1.5 |
BRANDO Production Picture:
More Refrigeration Products for you to choose:
|
|
|
|
| Refrigeration Solenoid Valve | 4 Way Reversing Valve | Expansion Valve | Hot Gas Bypass Valve |
|
|
|
|
| Crankcase Pressure Regulator | Check Valve | Sight Glass | Access Valve |
