| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 4V330C-08 |
| Minimum Order Quantity: | 200 PCS |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 200000 pcs per month |
| Product Name: | Pneumatic Solenoid Valve | Fluid: | Air |
|---|---|---|---|
| Port Size: | In=Out=Exhaust=1/4'' | Valve Type: | 5 Way 3 Position |
| Operating Pressure: | 0.15 To 0.8 MPa | Proof Pressure: | 1.2MPa |
| Body Material: | Aluminum Alloy | Coil Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| Highlight: | 4V330C-08 Solenoid Control Valve,5/3 Way Solenoid Control Valve,AirTAC 4V330C-08 |
||
4V330C-08 5/3 Way 1/4'' Solenoid Control Valve Close Center DC 24V
4V300 series includes 4V310-08 solenoid valves, 4V320-08 control valves, 4V330-08 pneumatic valves, and also 4V310-10 control valves, 4V320-10 solenoid valves, 4V330-10 pneumatic control valves. Those solenoid valves can be designated as internally piloted or externally piloted. Externally piloted valves use an external source of air pressure. Internally piloted use an internal source of air pressure.
Features:
1. Integral slot piston structure
2. Process valve hole with special high precision finishing process
3. Beautiful appearance
4. Good reverser
5. Reliable performance
6. Seal wear can automatic compensate
Technical Data of 4V300 Series Solenoid Valve:
|
Model
|
4V310-08
|
4V320-08
|
4V330C-08
4V330E-08
4V330P-08
|
4V310-10
|
4V320-10
|
4V330C-10
4V330E-10
4V330P-10
|
|
Fluid
|
Air (to be filtered by 40 μm filter element)
|
|||||
|
Acting
|
internal pilot or external pilot
|
|||||
|
Port Size
|
in=out=exhaust=1/4''
|
in=out=3/8'', exhaust=1/4''
|
||||
|
Orifice Size
|
4V310-10, 4V320-10: 28.0mm² (Cv=1.65)
4V330C-10: 21.3mm² (Cv=1.25)
|
|||||
|
Vlave Type
|
5 way 2 position
|
5 way 3 postion
|
5 way 2 position
|
5 way 3 position
|
||
|
Operating Pressure
|
0.15 to 0.8 MPa (21 to 114 psi)
|
|||||
|
Proof Pressure
|
1.2MPa (175psi)
|
|||||
|
Temperature
|
-20 to +70℃
|
|||||
|
Body Material
|
Aluminum Alloy
|
|||||
|
Max Frequency
|
5 cycle/sec
|
3 cycle/sec
|
5 cycle/sec
|
3 cycle/sec
|
||
|
Voltages
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
|
|||||
Main Dimension of 4V330C-08 Solenoid Valve:
Video of 4V330C-08 Solenoid Valve:
Production Video of Pneumatic Valve:
