12 Line Dust Collector Timer Controller Pulse Jet Valve Time Control
The pulse jet controller is the main piece of control equipment in the pulse jet dust cleaning system of baghouse. Its output signals control the electromagnetic pulse valves to blow and inject compressed air to remove dust from the filter-bag in sequence to keep the running resistance of the bag-house within the set range, thus guaranteeing the high processing ability and dust-collecting efficiency of baghouse.
Technical Data of Pulse Jet Valve Controller:
|
Model No
|
BC-08
|
BC-10
|
BC-12
|
BC-20
|
BC-24
|
BC-30
|
BC-36
|
BC-56
|
BC-64
|
|
Output Channel
|
1-8
|
1-10
|
1-12
|
1-20
|
1-24
|
1-30
|
1-36
|
1-56
|
1-64
|
|
Input Voltage
|
24VDC, 220VAC, Other voltage can be customized
|
||||||||
|
Output Voltage
|
24VDC, 220VAC, Other voltage can be customized
|
||||||||
|
Pulse Frequency
|
1 to 30 Seconds
|
||||||||
|
Pulse Durtion
|
0.03 to 0.2 Seconds
|
||||||||
|
Working Environment
|
1. -25°C~+55°C
2. The relative humidity of the air does not exceed 85%
3. No serious corrosion gas and conductive dust
4. No violent vibration or shock
|
||||||||
Main Dimension of Pulse Jet Valve Controller:
|
Output Lines
|
1-8
|
1-20
|
1-36
|
1-64
|
|
Dimension
|
115x135x65
|
160x160x95
|
230x150x90
|
248x188x105
|
Details Images of Pulse Jet Valve Controller:
Product Video of 12 Lines Pulse Controller:
