| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | RCA45T |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 10000pcs per month |
| Product Name: | Pulse Jet Valve | Pilot Size: | 1/8'', 1/4'' |
|---|---|---|---|
| Port Size: | 1.5'' | Series: | T |
| Valve Structure: | Right Angle, Threaded Port | Valve Body Material: | Aluminum Alloy |
| Membrane Material: | NBR, VITON | Operating Pressure Range: | 5 To 125 Psi |
| Highlight: | RCA45T Goyen Pulse Valve,Goyen Pulse Jet Valve 1.5'',RCA45T Goyen |
||
1.5'' RCA45T Goyen Type Threaded Pulse Jet Valve RCA45T001 RCA45T010
BRANDO has over 10 years of experience in the design and manufacture of pulse jet valves in dust collectors. Our threaded pulse valves are manufactured from aluminum in a high-pressure die cast process. T-series is designed to operate with air pressures from 5 to 125 psi. These threaded valves can be orientated in any position other than upside down or inverted.
The temperature range of the threaded valves depends on the chosen model and diaphragm:
NBR diaphragms: -40 °C (-40°F) to 82°C (179.6°F)
Viton diaphragms -29°C (-20.2°F) to 232°C (449.6°F)
Technical Data of T Series Pulse Jet Valves:
|
Model Number
|
RCA15T
|
RCA20T
|
RCA25T
|
RCA35T
|
RC45T
|
RCA50T
|
RCA62T
|
RCA76T
|
|
Office Size
(mm)
|
15
|
20
|
25
|
35
|
45
|
50
|
62
|
76
|
|
Port Size
(Inch)
|
1/2''
|
3/4''
|
1''
|
1 1/2''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
|
Diaphragm Number
|
1
|
2
|
||||||
|
Pilot Size
|
1/8'', 1/4''
|
|||||||
|
Working pressure
|
5 to 125 psi
|
|||||||
|
Diaphragm Material
|
NBR, VITON
|
|||||||
|
Body Material
|
Aluminum Alloy
|
|||||||
|
Valve Structure
|
Right Angle (Outlet is at 90° to Inlet), Threaded Port
|
|||||||
Ordering Code of T Series Pulse Jet Valve:
Main Dimension of 1.5'' RCA45T Pulse Jet Valve:
