| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | MD01-40, MD02-40, MD03-40 |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic bag, Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100000 sets per month |
| Product Name: | Pulse Jet Valve Diaphragm | Diaphragm Material: | NBR |
|---|---|---|---|
| Seat Material: | Nylon | 1 Set: | 1pc Big Diaphragm, 1pc Small Diaphragm, 2pcs Springs |
| Fitted Pulse Valve Port: | 1 1/2'' | Fitted Pulse Valve Model: | TH-5840-B, TH-5440-B, TH-4840-B, TH-4440-B, TH-5840-C, TH-5440-C, TH-4840-C, TH-4440-C, TH-5850-F, TH-5450-F, TH-4850-F, TH-4450-F |
| Highlight: | MD01-40 Diaphragm Repair Kit,MD02-40 Diaphragm Repair Kit,Taeha MD03-40 |
||
MD01-40 MD02-40 MD03-40 Diaphragm Repair Kit For Taeha Pulse Valve
MD01-40, MD02-40, MD03-40 Diaphragm (Membrane) for Taeha pulse valve TH-5840-B, TH-5440-B, TH-4840-B, TH-4440-B, TH-5840-C, TH-5440-C, TH-4840-C, TH-4440-C, TH-5850-F, TH-5450-F, TH-4850-F, TH-4450-F; Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.
Ordering Code of Diaphragm For Taeha Pulse Valve:
|
BRANDO Model
|
Reference Number
|
Port Size
|
Fitted Pulse Valve Model
|
Color
|
Material
|
|
DH20
|
MD01-20
MD02-20
|
3/4''
|
TH-5820-B
TH-4820-B
TH-5825-B
TH-5820-C
TH-4820-C
|
Red & Green
|
NBR
|
|
DH25
|
MD01-25
MD02-25
|
1''
|
TH-4825-B
TH-5825-C
TH-4825-C
TH-5840-F
TH-4840-F
|
||
|
DH25M
|
MD01-25M
|
1''
|
TH-5825-M
|
||
|
DH40
|
MD01-40
MD02-40
MD03-40
|
1 1/2''
|
TH-5840-B
TH-5440-B
TH-4840-B
TH-4440-B
TH-5840-C
TH-5440-C
TH-4840-C
TH-4440-C
TH-5850-F
TH-5450-F
TH-4850-F
TH-4450-F
|
||
|
DH40M
|
MD03-40M
|
1 1/2''
|
TH-5440-M
TH-4440-M
|
||
|
DH50
|
MD03-50
|
2''
|
TH-5450-B
TH-4450-B
|
||
|
DH50M
|
MD03-50M
|
2''
|
TH-5450-M
TH-4450-M
|
||
|
DH60
|
MD03-60
MD04-60
|
2 1/2''
|
TH-5460-B
TH-4460-B
TH-5460-S
TH-4460-S
|
||
|
DH75
|
MD03-75
|
3''
|
TH-5475-B
TH-4475-B
|
||
|
DH75M
|
MD03-75M
|
3''
|
TH-5475-M
TH-4475-M
|
Dimension of MD01-40, MD02-40, MD03-40 Diaphragm:
Main Diaphragm:
Secondary Diaphragm:
Video of MD01-40, MD02-40, MD03-40 Diaphragm:
Pictures of Solenoid Valve Membrane Production:
More Products For Taeha Pulse Valve for you to choose:
|
|
|
|
| Valve Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
