| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 6013 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union,Paypal |
| Supply Ability: | 50000 pcs per month |
| Port Size: | 1/8'', 1/4'' | Orifice Size: | 1.5mm, 2mm, 2.5mm, 3mm, 4mm, 5mm, 6mm |
|---|---|---|---|
| Function: | 2 Way Normally Closed | Operation: | Plunger Direct Acting |
| Body Material: | Stainless Steel | Seal Material: | NBR, EPDM, FKM |
| Temperature Range: | NBR: -10 To +80 ℃, EPDM: -30 To +120 ℃, FKM: -30 To +150 ℃ | Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| Highlight: | 6013 A 2.0 Solenoid Valve,6013 A 3.0 Solenoid Valve,Stainless Steel Solenoid Valve 6013 |
||
Stainless Steel Solenoid Valve 6013 A 1.5 2.0 2.5 3.0 4.0 5.0 6.0 1/8 5/64 FKM
The 6013 solenoid valve is a direct operated 2/2-way solenoid valve with a compact design, which is available in both NC and NO versions. It is a cost-effective valve with a universal application for neutral and clean liquids, gases and vapors. Some versions of this valve also allow for use in mildly acidic and alkaline solutions. Diverse body and seal material combinations along with a variety of certifications, provide for a universal solution for your application.
Technical Data of 6013 Solenoid Valve:
|
Model
|
Port Size
(Inch)
|
Orifice Size
(mm)
|
Kv
|
Pressure Range (bar)
|
Medium Temperature (℃)
|
Dimension
|
||
|
A
|
F
|
K
|
||||||
|
6013
|
1/8''
|
1.5
|
0.05
|
0 to 40
|
NBR: -10 to +80
EPDM: -30 to +120 FKM: -30 to +150 |
32
|
32
|
66
|
|
2
|
0.12
|
0 to 25
|
||||||
|
2.5
|
0.16
|
0 to 16
|
||||||
|
3
|
0.23
|
0 to 10
|
||||||
|
1/4''
|
1.5
|
0.05
|
0 to 40
|
46
|
32
|
70
|
||
|
2
|
0.12
|
0 to 25
|
||||||
|
3
|
0.23
|
0 to 10
|
||||||
|
4
|
0.3
|
0 to 4
|
||||||
|
5
|
0.35
|
0 to 2
|
||||||
|
6
|
0.55
|
0 to 1.5
|
||||||
|
Sub-base
(SFB)
|
1.5
|
0.1
|
0 to 40
|
32
|
32
|
66/68
|
||
|
2
|
0.15
|
0 to 25
|
||||||
|
3
|
0.23
|
0 to 10
|
||||||
